Instructions for Use

3.2 Technical data

Display:
Touch surface:
Radio (integrated): ISM frequency band: 433.150 MHz – 434.650 MHz
Energy supply:
Environment:
Dimensions:
Weight:
Options:
Additional information on the options can be obtained from your specialist
retailer.
Highly transflective and sunlight resistant graphics
technology for 160 x160 pixels with adjustable LED
back light
Anti-glare surface over the entire display and menu
card area, 5 programmable on-screen buttons,
adjustable LED backlight
(USA, Canada option: 902.200 MHz – 905.200
MHz);
Transmitting power less than 10mW - bidirectional
data transfer;
Range in buildings: Up to 50 meters with an area
coverage up to 7,800 m²; range outside: Up to 300
meters.
Bluetooth V1.1 (class 2)
Lithium ion rechargeable battery: 1,200mAH;
charging time: approx. 4 hours in handset, approx.
60 minutes in Orderman Max charging station
(option)
Power supply: Default values: 7.5V / 900mA;
input values: 100V-240V / 50Hz-60Hz;
max. Power consumption: 84mA / 19.4VA
Operating time: Up to 18 hours online duration
Fall proof: 1.2 meters onto concrete
Waterproof: IPX4
Operating temperature: -5° to +50° C
Storage temperature: -10° to +60° C
L x H x W: 180mm x 86mm x 24mm
Handset: 220g; battery: 40g
Orderman Card swipe
Orderman Legic and ISO transponder reader
Orderman order card
Orderman order card and Orderman card swipe
- 14 -
Handset
Max
