Mixmaster User's Guide
2

Product information

2.1

Minimum system requirements

Your Mixmaster is designed to operate with any Automotive PC Oscilloscope from
Pico Technology. Please check that your computer meets the requirements stated in
the User Manual for the oscilloscope.
2.2

Connectors and controls

Battery compartment
underneath
Low battery indicator
Bank A cylinder 1
and trigger input
cylinders 2 to 6
Output A selector switch
Trigger output
Output A
4
Bank A
inputs
Power
switch
Pico Technology
Power indicator
Bank B
cylinders 1 to 6
inputs
Bank B polarity switch
Ground terminal
Output B
DO120-3
