LED indicator status of Power key, notebook and adapter
Dock with adapter
Connected to power
supply
Disconnected from
power supply
Using your ASUS Triple 4K Thunderbolt™ 4 Dock
B
A
Notebook status
N/A
Shutdown (S5)
Hibernate (S4)
Suspend (S3)
Powered on
N/A
Shutdown (S5)
Hibernate (S4)
Suspend (S3)
C
D
Power Key Status
Solid orange
Solid white
Off
To use your ASUS Triple 4K
Thunderbolt™ 4 Dock:
A. Connect the AC power cord to
the AC/DC adapter.
B. Plug the AC power adapter into
a 100V~240V power source.
C. Connect the DC power
plug into the power (DCIN)
port of your ASUS Triple 4K
Thunderbolt™ 4 Dock.
D. Connect the Thunderbolt™ 4
cable to your Notebook PC.
