Mission time
Mechanical data
Mechanical life, minimum
Actuating play in direction of actuation
Holding force F
in accordance with EN ISO 14119
Zh
Holding force F
, maximum
max
Latching force
Positive break travel
Positive break force per NC contact, minimum
Positive break force, minimum
Actuating speed, maximum
Mounting
Type of the fixing screws
Type of the screw head
Mechanical data - Connection technique
Cable entry
Termination
Cable section, minimum
Cable section, maximum
Note (Cable section)
Allowed type of cable
Mechanical data - Dimensions
Length of sensor
Width of sensor
Height of sensor
Ambient conditions
Degree of protection
Ambient temperature
Storage and transport temperature, minimum
Storage and transport temperature, maximum
Note (Relative humidity)
20 Year(s)
1.000.000 Operations
5,5 mm
2.000 N
2.600 N
30 N
10 mm
10 N
30 N
2 m/s
Schrauben
3x M5
Flachkopfschraube
2 x M16 x 1,5
Federkraftklemmen
0,25 mm²
1,5 mm²
Alle Angaben einschließlich Aderendhülsen.
Starr eindrähtig
Starr mehrdrähtig
Flexibel
30 mm
130 mm
90 mm
IP67
-25 ... +60 °C
-25 °C
+85 °C
nicht kondensierend
nicht vereisend
6-18
