CV
Explanation
Storing different states:
Bit 0: Storing function states
173 PoM Bit 1: Storing speed
Bit 2: After a reset starting up with/without ABV
Bit 3 - 7: always 0
Storing different states:
174 PoM Bit 0: Storing direction of travel
Bit 1 - 7: always 0
176 PoM Vmin Analog DC
177 PoM Vmax Analog DC
178 PoM Vmin Analog AC
PoM
179 Vmax Analog AC
CV 31 must first be set to the value 16 and CV 32 to the value 0 (see CV 31) to change the volumes (CV 300 - CV 328).
PoM
300 Sound output: Volume of running sounds*
301 PoM Sound output: Volume for Sound 1*
- up to
328 PoM Sound output: Volume for Sound 16*
PoM must be supported by the locomotive
controller / central controller.
46
CV Table for DCC
Values
Default
0 / 1
0 / 2
0 / 4
0 / 1
0 - 255 50
0 - 255 170
0 - 255 60
190
0 - 255
0 - 255 180
0 - 255 180
0 - 255 180
* An extensive table for function mapping can be found on the Internet at:
www.maerklin.de/de/produkte/tools_downloads/technische_infos.html
Notes
0 = do not store, value = store
7
Individual values must be added.
0 = do not store
1
1 = store
Must be smaller than CV 177
Must be larger than CV 176
Must be smaller than CV 179
Must be larger than CV 178
0 = no sound
