LD Systems MEI1000 Bedienungsanleitung Seite 7

10
SLIDE UNDER CLIP
WHEN MOUNTING
TO A BELT
LD MEI1000BP BODYPACK FEATURES:
Earphone volume control and On/Off switch
1
2 Earphone plug
3 Antenna
4 LCD screen
Please see "SYSTEM SETUP" on page 10.
Low battery indicator
5
Power LED
6
Glows when device is turned on.
Receiver menu up button
7
Receiver menu down button
8
ESC button
9
Exits setup menu.
SET button
10
Use this to select setup parameters.
Wearing the Bodypack Receiver
Clip the receiver to a belt. For ultimate results, clip the receiver onto
a belt by pushing the receiver down onto the belt as far as it goes.
For guitarists, attach the guitar strap"through" the receiver clip.
Replacing the Batteries
The expected runtime for two alkaline batteries is approximately 10 hours
(depending on operating volume and battery model).
When the LCD panel battery sign flashes (see below) the batteries should
be replaced immediately.
07
