UV-A/White Light LED NDT Inspection Lamps
Part Nos. TRI-365MHB, TRI-365MDB, TRI-365MDBB
INTRODUCTION
The TRITAN™ 365 AC/DC series UV LED Inspection lamps are equipped with a cord ending in a
male connector plug and an AC/DC adapter cord appropriate for the country of destination. The kit
includes a 12V 3000mAHr NiMH rechargeable battery in a case with an adjustable shoulder strap.
Each smart battery charger is equipped with the cord appropriate for the country of destination
(120V, 230V, 240V or 100V). All components are packed in a sturdy, padded carrying case.
UV light emitted from this product. Avoid eye and skin exposure to unshielded products.
IMPORTANT SAFETY INSTRUCTIONS (Read all instructions)
•
Do not operate the lamp with a damaged cord or if the lamp has been damaged.
•
Never use this equipment in any manner not specified in these instructions because the
protection provided by the equipment may be impaired.
•
The TRITAN 365 is not approved for use in hazardous atmospheres. Do not attempt to use
it in areas requiring explosion-proof lighting.
CHARGING
The BP-30 battery pack must be fully charged before first use.
•
Check that the voltage characteristics of the battery charger match the voltage of the
AC outlet.
•
Align the male connector of the smart charger (BR-150A) to the female connector of the
battery pack (BP-30) and plug them together. Twist the ring on the charger connector to
make a tight connection.
•
Attach the AC cord supplied to the BR-150A charger and plug the unit into a properly
regulated AC outlet.
The indicator light on the charger will show Red while it is charging and Green when the
•
battery is charged. A full charge will take approximately 2 hours.
•
After the battery is charged, first unplug the charger from the outlet, then unplug it from the
battery pack.
WARNING: Use only the charger supplied to recharge the battery. Other chargers may harm the
battery and will void the battery's warranty.
CHANGING THE LAMP CORD
•
The appropriate cord for the country of destination will be installed on the lamp when it is ordered.
To separate the cord from the lamp, turn the locking device at the top portion of the bayonet
connector counterclockwise (see Figure 1).
•
To attach a new cord, align the small peg on the lamp handle's terminal to the corresponding
groove on the cord's terminal connector, and push them together carefully so that the pins do not
become bent. Turn the locking device on the top portion of the bayonet connector clockwise until
secure (see Figure 2).
For AC Operation
•
Align the male connector of the lamp to the female connector of the AC adapter (PSA-250A)
and plug them together. Twist the ring on the adapter connector to make a tight connection.
Attach the plug to the corresponding AC power source.
•
The lamp has a three-position rocker switch (O–off; I–white light; II–UV light) located on the
handle. Press the switch into the desired light source position to light and use the
TRITAN 365.
You must wear the UV-absorbing spectacles supplied. The lamp should be used in
low-light conditions to achieve the best inspection results.
TRITAN™ 365 AC/DC SERIES
FOR PROFESSIONAL EXAMINATION USE ONLY
IMPORTANT
WARNING
2
