Technical Data - Velux W+RE B/4 Anleitung

Indication
The 2-colour LED shows the operating status.
Diagnostics via 2-colour LED
Green continuous light
Green flashing light
Red continuous light
Red flashing light
Connection
Terminal X1 = mains connection / 230 V / 50 Hz)
Terminal X2 = external group extension or external indication
Terminal X3 = 4 switching contacts (change-over)
Terminal X4 = sensor connection (wind/rain sensor, ext. All groups CLOSED)

Technical data

Supply voltage
Fuse
Power consumption with max. group extension
Group extension
Switch outputs
Switch capacity
Housing colour
Housing dimensions
Housing weight
Sensor dimensions
Sensor supply voltage
Sensor weight
Sensor protection degree
Setting of wind actuation
Setting of wind/rain drop-out delay
CE mark
4 VELUX
®
Automatic ON
Manual mode ON
Triggered by rain,
All groups CLOSED
Triggered by wind
Miscellaneous
The control unit must be connected by qualified personnel in compliance
with local regulations.
The sensor must be cleaned regularly depending on how dirty it is.
230 V AC / 50 Hz
F1 = T 315 mA
75 V A
230 V AC / 50 Hz (max. 280 mA)
4 x potential-free change-over contact
4 x 230 V AC / 5 A (Note: max. 10 motors per group)
Light grey (RAL 7035)
200 x 150 x 80 mm (WxHxD)
Approx 1 kg
80 x 160 x 55 mm (WxHxD / without wind wheel)
24 V
Approx 0.7 kg
IP65
Approx 3 to 14 m/s (± 20 %)
10 min. / 20 min.
In accordance with the EMC Directive and the Low Voltage Directive
