Operation/ Function
Change-over switch "All groups CLOSED / Automatic" in the
Automatic position
Rain-triggered actuation
When triggered by the rain sensor, all motors close. The 2-colour
diagnostic LED shows a red, continuous light.
Note: The ventilation switches are blocked as long as the rain sensor is
actuated. Depending on your settings, the wind sensor will be reset
10 or 20 minutes after the last sensor actuation.
It is possible to switch to ventilation switch mode even if the rain sensor
has been triggered (see manual mode).
Manual mode (timed ventilation)
By pressing the push button ("Hand" on the door front), the rain trigger
can be deactivated. The motors can OPEN via the ventilation switches
even if the rain trigger is activated. The 2-colour diagnostic LED flashes
green.
After approx. 30 minutes or after pressing the push button again, the
rain trigger is active again.
Change-over switch "All groups CLOSED / Automatic" in the
All groups CLOSED position
The 2-colour diagnostic LED shows a red, continuous light. All groups
CLOSED is a permanent signal and has priority over all other operating
modes. All functions are blocked.
An external All groups CLOSED switch (potential-free make (N/O)
contact) can be connected.
Transmitting a wind or rain-triggered actuation
An external group extension or alarm (max. 60 W) can be connected to
terminal X2. When a sensor has been actuated, 230 V are switched on
with a maximum current load of 280 mA.
L1 = permanent contact
Various wind and rain parameters and operating modes can be set with the
integrated DIP switches.
DIP switch settings for wind speed
Test
Switch 1
OFF
Switch 2
OFF
Switch 3
OFF
Approx.
8 m/s
Switch 1
OFF
Switch 2
ON
Switch 3
OFF
Important:
Factory setting = test setting!
Make the necessary wind speed settings once the
device has been activated!
Note: In test setting, drop-out delay is deactivated!
Recommended setting: 8 m/s.
DIP switch settings for wind/rain drop-out delay
The wind/rain signal is saved 10 or 20 minutes (settable).
Switch 4 = wind/rain drop-out
delay
Settings
Approx.
Approx.
Approx.
3 m/s
4 m/s
6 m/s
ON
OFF
OFF
OFF
OFF
ON
Approx.
Approx.
Approx.
10 m/s
12 m/s
14 m/s
ON
OFF
ON
ON
OFF
ON
Switch position
Switch position
OFF
ON
10 minutes
20 minutes
ON
OFF
ON
ON
ON
ON
