Faceshield Replacement
EN
EN
NOTE: THE FACESHIELD CAN ONLY BE REMOVED OR INSTALLED
IN THE FULLY OPENED POSITION!!!
To remove your faceshield, place the helmet in front of you with the eye port
facing away, ratchet the faceshield up to the fully open position. Rotate both
circular SpeedShiftTM clockwise. The shield will release immediately from the
SpeedShiftTM: T hen simply pull or "peel" the shield off the helmet.
To install a faceshield, center the shield's pivot holes over the SpeedShiftTM
pivot ratchets in the open position (up) place shield shield screw top inside
edge from black ratchet system plate and press squarely inward, using your
fingertips of the palm of your hand. Openand close the shield fully to test its
secure installation before riding
Before riding, open and
close the faceshield
completely to test
whether it is installed
correctly.
5
Securing and Wearing
Your Helmet
WHEN Donotsimplypull yourhelmetdownontoyourheadlikea hat.YourScorpionExo@
helmet should be worn as follows: Using both hands grab the helmet's bottom rim
while holding the chin straps with your thumbs. Then "roll" the helmet onto your
head starting at the forehead. Continue rolling the helmet on towards the back of
the head until it comes to rest with your head fully in contact with the inner lining
and cheek pads.
HOW TO USE CHINSTRAP
Nylontab
While you are wearing your helmet,
Locking brace
grasp the notched arm of the
Openslot
chinstrap with your right hand, and the
locking mechanism with your left
Notched arm
hand. Pull the nylon tab with your
thumb and forefinger to open the
locking brace. Insert the notched arm
into the slot. Releasethe nylon tab to
lock the arm in place. Adjust as
needed.
FIRMLY AND SECURELY FASTEN YOUR CHINSTRAP.
Check your chinstrap for tightness occasionally as vibration or wind may
oosen it.
Cleaning Your Helmet System
Noneof the components of yourScorpionExo@ h elmetcanbe damaged
by water. All headliners and sweat-wicking cheek pads are machine
washable. Wash them with a mild detergent in warm water and allow to
air dry. Handwashing is recommended, but machine washing is also
permitted. Use the "delicate" cycle to prevent the agitator
from damaging the sweat-wicking material covering the liner parts,
we recommand to place the parts in a washing bag. Do not place
lining parts in the dryer: Excessheat may damage the foam and
coverings. The faceshield may be cleaned with plastic polish or
mild soap and water. The shell of your helmet should be cleaned
using only a mild detergent and water.
Warning
Foryour safety, it is important that you completely read the
owner's manual and all warning labels.
DO NOT
DONOT ride without snugly fastening your chinstrap.
DONOTcleanyourhelmetwith petroleumproducts,solvents,
benzene,thinner or cleaning agents.
DONOT paint over your helmet's finish without totally protecting
and isolating the shock-absorbing liner and plastic parts
Your warranty will otherwise be invalidated.
DONOTdrop yourhelmetfrom any heightontoa hardsurface.
This could cause damage to your helmet's finished and/or
decrease its ability to protect you.
DONOT placeyour helmet on your motorcycle'srearview mirror:
The sharp pressure from the mirror's edge will compress and
damage the helmet's shock-absorbing liner.
DONOT place your helmet on the motorcycle's seat or fuel tank.
It can easily roll off and hit the ground causing damage to
the helmet. It is best to place your helmet on the ground so it
cannot fall in any direction.
DONOTridewith a scratchedfaceshield. T hiscan impairyour
vision, especially at night.
DONOT modify any part of your helmet, e.g., drilling the shell or
cutting and pressing the shock absorbing liner. Installation of
sound systems, speakers and microphones reduces your helmet's
ability to protect you and is not recommended.
DONOTuse the helmet again if it has either been dropped or
involved in an accident. Replace it even if the damage is not
visible to the naked eye.
DONOTwear a dark or tinted faceshield (including the
retractable SpeedViewTM Sunvisor) i n dark or poorvisibilityriding
conditions.
DONOTplace your headliners and cheek pads in the dryer after
washing. Allow them to air dry.
DONOTattempt to remove,change or replace your faceshield
while riding your motorcycle or ATV.
DONOTuse paint which requires heat curing
Warranty
All ScorpionExoTM helmets have a warranty of 5 years.
Although there is no visible damage on your helmet, general wear
and tear over time may affect overall function of protective helmet
and increase the risk of injury in accident. It is advisable to replace
your helmet no later than every 5 years from purchase.
Should you have a warranty claim, go to your Scorpion dealer with
your invoice (this is you purchase proof, it's necessary in order to
start the warranty process). Youcan find our dealers list on your
website: http://www.scorpionsports.eu/english/dealers/find-a-dealer/
find-a-dealer.html (choose your country and then the location)
The dealer will contact our after sales service
and start the warranty process in order to check
and/or repair your helmet. YEAR
WARRANTY
