• Operate the product on a flat surface only.
• The use of accessories not explicitly recommended by the manufacturer could
cause injuries and damage. For that reason, only use original accessories.
• Do not pour any hot liquids into the beaker.
• Consult an expert when in doubt about operation, safety or connection of the
device.
• Maintenance, modifications and repairs are to be performed exclusively by an
expert or at a qualified shop.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.

Operating elements

1
2
3
4
1 Lid
2 Beaker
3 Tongue
Before first-time use
• Remove the packaging material.
• Clean the beakers, lids and blade unit (see "Cleaning and care").
• Let all parts dry completely.

Important notes

• The product is not suitable for making beaten egg white, cream, mashed potatoes, minced
meat, or dough.
• Do not process any hard foods (e.g. beets), frozen foods, or bones.
• When processing dry foods, add sufficient liquid.
• When crushing ice cubes, hold the beaker securely with one hand.
• Pit and peel fruits and vegetables before adding those to the beaker.
• Cut fruits and vegetables into small cubes of approx. 15 mm in length.
• If overloaded, the motor will stop automatically. In such a case, disconnect the mains plug
from the wall socket. Remove part of the food from the beaker. Wait for 15 minutes for the
motor to cool down, before switching the product on again.

Operation

• Install the base station on a horizontal, flat, stable surface.
• Push the base station down for the suction cups to adhere to the surface.
• Fill the beaker with the cut ingredients.
Do not exceed the MAX marking.
• Screw the blade unit onto the beaker.
• Connect the power plug to a common household power outlet.
• Attach the beaker to the base station upside down.
The 3 tongues on the edge of the beaker must be aligned with the 3 recesses of the
base station.
• Push the beaker down. The motor starts running.
• If needed, turn the beaker clockwise for the beaker to lock into place.
• When unlocking or releasing the beaker, the motor will stop.
• Remove the beaker from the base station.
• Remove the blade unit from the beaker.
• Screw the lid onto the beaker.
5
6
4 Blade unit
5 Base
6 Suction cup
Cleaning and care
a) Base
• Under no circumstances use aggressive cleanings agents, cleaning alcohol or other chemical
solutions since these can penetrate the housing or impair functionality.
• Never submerge the product in water or other liquids.
• Disconnect the product from the power supply before cleaning.
• Clean the product with a dry, fibre-free cloth.
b) Beaker, lid, blade unit
• Clean all parts by hand. None of the parts are dishwasher-safe.
• Be careful when cleaning the blades. There is a risk of injury!
• Clean the parts with warm water and a mild detergent.
• Thoroughly rinse all parts with water.
• Let all parts dry completely before using them again.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product in accordance
with applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the
environment.
Technical data
Operating voltage ......................... 220 – 240 V/AC, 50/60 Hz
Power consumption ...................... 300 W
Capacity ........................................ 570 ml / 400 ml
Idle speed ..................................... 22000 rpm ±15 %
Noise level .................................... ≤85 dB (at 1 m distance)
Cable length ................................. approx. 1.2 m
Protection class ............................ II
Operating time .............................. 30 sec. on/ 15 min. off
Material ......................................... ABS (housing)
Stainless steel (blades)
Tritan (beaker)
Operating conditions ..................... -15 to +40 °C, max. 85 % RH
Storage conditions ........................ -20 to +45 °C, max. 85 % RH
Dimensions (Ø x H) ...................... 132 x 191 mm (base station)
132 x 235 mm (base station + small beaker)
132 x 387 mm (base station + big beaker)
Weight .......................................... approx. 1.2 kg
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represents the technical status at the time of printing.
Copyright 2017 by Conrad Electronic SE. *1518537_V1_0217_02_IPL_m_en
