4. If needed, use the removable block
24, pos. 4) on thinner walls or window
frames.
5. Make sure the outdoor unit
24, pos. 1) hangs level by tightening the
nut (Figure 24, pos. 2) on the adjustment
bolt spacer . Make sure the bumper
(Figure 24, pos. 3) is placed vertical.

Indoor unit installation

The indoor unit can be placed on a sturdy table or it can be placed hanging on support brackets.
Support brackets (optional)
1. Attach the top caravan brackets
25, pos. 1) to the bottom caravan brackets
by tightening the screw cap per bracket
(Figure 25, pos. 2).
(Figure
(Figure
(Figure
Figure 24.
Figure 25.
27
