Danfoss RT 6W Installationsanleitung

Installation guide
Pressure switch
RT 6W, RT 6B, RT 6S, RT 6AW, RT 6AB, RT 6AS, RT 30AW, RT 30AB, RT 30AS with
EN 12263 approval and CE marked acc. to PED (Pressure Equipment Directive)
Refrigerants*):
R22, R134a, R404A, R407A, R407C, R407F, R422B, R422D, R507A, R717**)
RT 6W, RT 6B, RT 6S
Fig. 1
Fig. 4
RT 6, RT 36:
1m, ¼ in x ¼ in flare
Code no.
060-007166
Fig. 8a
Enclosure
(1)
Tæthedsgrad
(1)
Type /
Schutzart Reset
(1)
Typ
Degré
d'étanchéité
(1)
RT 6W
IP66 automat.
RT 6B IP54 man. ext.
RT 6S
IP66 man. int.
RT 6AW IP66 automat.
RT 6AB
IP54 man. ext.
RT 6AS IP66 man. int.
RT 30AW
IP66 automat.
RT 30AB IP54 man. ext.
RT 30AS
IP66 man. int.
Fig. 10
according to / i.h.t. / nach / conformément à EN 60529 / IEC 529
(1)
© Danfoss | Climate Solutions | 2021.10
Fig. 5
RT 6, RT 36:
1m, 3/8 in x M10 – 0.75
Code no.
060-008266
Fig. 8b
Pressure range Differential (fixed)
Trykområde Differens (fast)
Druckbereich Differenz (fest)
Plage de pression Différence (fix)
Δp
[bar] [bar]
5 – 25 3.0
10 – 28 max. 1.0
5 – 25 3.0
10 – 28 max. 1.5
0.8
1 – 10
max. 0.4
Fig. 6
Max. working press.
Till. driftstryk
Refrigerants
Zul. Betriebsüberdruck
Kølemidler
Press. de service max.
Kältemittel
Réfrigérants
[bar] / [psig]
fluorinated refrigerants
fluoreded kølemidler
fluorierte Kältemittel
réfrigérants fluorés
R 717 (NH )
3
+ fluorinated refrigerants
+ fluorerede kølemidler
+ fluorierte Kältemittel
+ réfrigérants fluorés
-50 – 70 °C without PED
(2)
RT 6AW, RT 6AB, RT 6AS
RG
BSP
R
G
Fig. 2
RT 30AW, RT 30AB, RT 30AS
RG
BSP
R
G
Fig. 3
Fig. 7
Code no.
017-425166
Fig. 9
Max. test press.
Max. prøvetryk
Max. Prüfdruck
Press. d'essai
PB / MWP
[bar] / [psig]
28 / 406 38 / 551
22 / 319 25 / 363
AN21698644089801-000302 | 1
089
Ambient temp.
Omgivelsestem.
Umgebungstemp.
Temp. ambiante
[°C]
-40 – 70
(2)
