Sound Pool Falcon
Interfaces
21
8 Digital
mixer
(Yamaha 02R
or
Korg
Sound
Link)
8.1
Digital
mixer as wordclock master
Connect
the mixer
and
the
computer
with the optical or coaxial cables.
The mixer
is
the
wordclock master and
the
computer
the
wordclock
slave. Select the
mode
44.1
INT
or
48
INT from wordclock
menu
(Yamaha
02R). Select 'external
wordclock'
at the
computer.
Cubase Audio: Hardware setup
-
input
ADAT
(this
is
always
external)
AudioTracker:
Audio parameter
-
input
ADAT
and
playclock external
Please note:
In
this
mode
playback only with the
mixer's
wordclock
is
recommented.
If
a
DIGITAL
I/O
Error!
message
appears, you have to switch the
computer
to external wordclock.
8.2
Digital
mixer as wordclock
slave
If
the
computer
only
sends data
to the mixer,
you can use the quartz clock
of
the Falcon's
SPDIF
interface. All
clock
sources can be used
for playback. Select
ADAT
input
from
the
wordclock
menu
at
the mixer.
9
ADAT
Interface
Features
Power
supply:
ADAT
Input:
ADAT
Output:
Falcon
Port:
SPDIF/FDI
Port:
9
V,
500
mA
Optical
Connector (TOS
Link)
ADAT
Format
Optical
Connector (TOS
Link)
ADAT
Format
D-Sub,
SoundPool
Format
D-Sub,
SoundPool Format
10
Trademarks
Atari'", Falcon'",
ADAT'",
Alesis'", Fostex'", Korg'",
Yamaha'",
Philips'", Sony'",
Steinberg'" are registrated
trademarks.
SouncIPooI
Analog
8/4 Interface for Falcon
MANUAL
Last updated: January
10,
1997
