Observing the position of the toilet actuator plate
The toilet actuator plate can be mounted from the
front or top with reduced frame heights (#WD1016,
#WD1018).
> Check that the transport lock has been removed
before installing the panelling.
• Panelling for actuation from the front:
> install the panelling at the front.
> Install the panelling at the top until the top
panelling butts against the front panelling.
• Panelling for actuation from the top:
> install the panelling at the top.
> Install the panelling at the front until the top
panelling butts against the top panelling.
