xenium X-DSP Benutzerhandbuch Seite 22

FUNCTIONAL INSTRUCTIONS
OPTICAL
INPUT
BROWN/BLACK
SUB R –
BROWN
SUB R +
ORANGE/BLACK
SUB L –
ORANGE
POWER
SUB L +
PURPLE/BLACK
REAR R –
PURPLE
REAR R +
REMOTE FEATURES AND OPERATIONAL CONTROLS
1
With this knob the overall volume of the sound system can be controlled. If you press and hold the knob for 3 seconds, the bass
level of output SUB OUT (G / H) can also be controlled.
The LED display shows the values when turning the knob (# 1) or the number of the selected settings.
2
With the two MODE buttons you can choose between the settings, which are stored in the DSP.
3
Use the buttons
With the INPUT SEL. button you are able to switch between the signal inputs of the audio sources MAIN, AUX IN and OPTICAL.
4
MAIN is the input LINE IN (Page 21, #6) and HIGH LEVEL INPUT (Seite 21, #7) as well as SUB IN (Page 21, #5).
Important note: The remote control must always be connected.
22
CABLE SET HIGH LEVEL INPUT
X– DSP DIGITAL SOUND PROCESSOR
SUB R SUB L
REMOTE
A B C
1
VOLUME
–
to select the desired setting and confirm with OK (# 3).
ASSIGNMENT
RR RL FR
HIGH LEVEL INPUT
OUTPUT
D E F
2
X– DSP
+
MODE OK
3
MAIN
POWER INPUT
FL
INPUT
WHITE
FRONT L +
AUX
INPUT
WHITE/BLACK
FRONT L –
GREY
FRONT R +
GREY/BLACK
PC CONNECT
FRONT R –
GREEN
REAR L +
G GREEN/BLACK H
REAR L –
MAIN
AUX
OPTICAL
INPUT
4
GND
+12V
REM IN
REM OUT
USB
