Schreder TFLEX COMBI Installationsanleitung Seite 13

F
B
1564.1 mm
A1
61.57 in
1175.1 mm
A2
46.26 in
786.1 mm
A3
30.94 in
1
01-55-960 | DOC-0018753 rev K | 03-2022
HOOK FIXATION
A1
440 mm
B C
17.32 in
Adjust hooks following cable tray size
W100 400 mm (25mm steps)
www.schreder.com
Ansi3G
A3
A2
GB + 1OB
225,5 mm
GB + 2OB
kg/lb
8.88 in
±1 kg
GB + 3OB
111 mm
4.37 in
C
16 kg
32.2 lb
23 kg
50.70 lb
32 kg
70.50 lb
13/17
