VALVE
To access the valve, unscrew the security screw counter-
clockwise. To open or close the valve, move the spring-loaded
needle. To close the valve, set the needle in upward position-
press the needle and rotate it clockwise, until the needle locks in
the upward position.
INFLATING
1. Connect the pump nozzle to the board valve, rotate it clockwise
and start pumping.
2. After inflating the board disconnect the nozzle and close the
security screw.
Caution: after leaving the board on sunlight, check the board air
pressure.
DEFLATING
Clean the board from water and the valve from debris. Unscrew
the security screw. Press the valve needle and slowly deflate the
board. After 10 seconds push the valve needle all the way down
until it locks down in open position. During deflating prevent the
sand and other debris from getting into the valve.
Caution: the board valve is not tightened all the way down in the
production process. To avoid the air loss, tighten the valve using
the valve key. Unscrew the security screw, insert the key and
rotate it to "CLOSE" position. During this process hold the valve
and make sure not to over tighten it.
FIN INSTALLATION
The fin can be installed when the board is inflated, as well as
deflated.
8
EN
STORAGE
1. Deflate the board and take out the fin.
2. Clean and check every segment and accessories (including the
paddle) after each use. If the product was used in a salt water,
make sure to remove all the water from the board. To clean the
board use mild soap, do not use any detergents or silicone-
based products. Make sure to dry the board before storage.
3. Keep the valve open when folding the board. Close it while
using the board.
4. Store the board in dry and clean place, where the temperature is
constant. Store the board deflated and folded in the bag, or folded
and slightly inflated. Do not expose the product to deformation.
5. Store the paddle disassembled.
FIXING LEAKS
Included in set are PVC patches for fixing small leaks.
1. Make sure that there are no sand or debris in the valve.
2. Make sure that the valve gasket is in place.
3. Clean the board with soap and water, including the valve.
4. Clean thoroughly the leak spot.
5. Cut the piece of patch in a way, that it covers 1,5 cm from the
leak spot.
6. Put a thin layer of glue onto patch and leak spot. Wait 2-4
minutes until the glue sets.
7. Put the patch on the leak spot and apply pressure. Do not use
the board for the next 24 hours until the glue dries.
