Hardware connection

Front Panel

The front panel GS1016 is shown as the following figure
The front panel of GS1024 is shown as the following figure.
LED and Interface Explanation
Power
ON
OFF
LINK/ACT
10/100M
1000M
Figure 1-1
Front Panel of GS1016
10/100/1000 Mbps
LEDs
Front Panel of GS1016
Figure 1-2
LEDs
Green
-
Orange
Green
4
RJ45 Port
10/100/1000 Mbps
RJ45 Port
