ROBENS CONIVAL 3IN1 PUMP Bedienungsanleitung Seite 2

1. INSTALLATION & USE
1. The rechargeable 3in1 pump can be charged by the included charging
cable (12).
2. Fully charge the battery before first use.
3. Remove the charge port cover (3), and connect the USB-C male plug (13)
to the USB-C charging input (9) on the 3in1 Pump.
4. Plug the USB-A male plug (14) into a suitable power source (5VDC, 2A).
5. A full charge from 0 – 100% takes app. 3 hours (5VDC, 2A).
6. When charging the battery indicator (8) will show the current battery
level (solid dots) and charging status (blinking dots). 4 solid dots equals
a fully charged battery.
7. The 3in1 Pump can also be charged using the integrated solar panel (11).
8. Place it outside with the solar panel facing upwards. Ideally positioned
perpendicular to the sun, so that the suns rays hits the panels on a 90°
angle.
Pump function:
1. Select a suitable valve adapter (15) and attach it to the inflation port (4),
or deflation port (5) on the 3in1 pump, depending on whether you wish
to inflate or deflate an item.
2. Remove the cover on the item you would like to inflate/deflate, and
connect the 3in1 pump with adapter to the valve on the item.
3. Activate high mode:
With the pump and adapter connected to the valve on the item, press
the on/off switch for pump (1) twice in a row. This will activate the high
mode (4.5kPa, 300L/min).
4. The battery indicator (8) will turn on, and indicate that the pump is
running, as well as the current battery capacity from 1-4 dots.
Activate low mode:
5. Press and hold the on/off switch for pump (1) to activate the low mode
(2.5kPa, 150L/min).
Low mode is ideal for inflating smaller items and to prolong battery
capacity.
6. The pump is turned off by toggling through the pump mode cycles until
the end.
7. When deflating it might be necessary to pinch the valve with your
fingers to open the flapped inside the valve to allow air to escape.
8. To inflate a Robens self-inflating mat or airbed use the grey Robens FHF
valve adapter with an "R".
Lantern function:
1. The lantern is turned on by pressing the on/off button switch for lantern
(2) marked with a sun symbol.
2. The battery indicator (8) will turn on, and indicate that the lantern is on,
as well as the current battery capacity from 1-4 dots.
3. Press the power button (2) additional times to toggle through the three
different light modes:
Low: 50 lumen
Mid: 100 lumen
High: 150 lumen
4. The lantern is turned off by toggling through the light modes.
5. The lantern can be used hanging, standing or as a handheld flashlight.
6. The lantern can be used as a work light while using the pump.
Powerbank function:
Lamp can also be used as a power bank to charge phones, gadgets etc.
1. Connect the USB-A male plug (14) to the USB-A powerbank output (10)
on the 3in1 Pump.
2. Connect the USB-C male plug (13) to the appliance you would like to
charge.
2. CLEANING & MAINTENANCE
The pump can be cleaned with water and a damp rag.
Do not use corrosive liquids to clean the pump as this might damage the
product.
3. LIGHT SOURCE: LED
Light source and control gear is not replaceable.
This would introduce weak points in the construction,
that could reduce the lifetime of the product.
4. DISASSEMBLY & DISPOSAL
If the product is no longer functional, follow the below instructions.
Disconnect the pump from any power source before starting the disassem-
bly process.
Break unit body using a hammer or use a sharp tool along the joint of the
pump to separate the parts. Remember to wear eye protection.
Disconnect and cut the wires, and dispose of the pump unit, PCB board,
charging cable, solar panel and wires as electronic waste.
Dispose of batteries as battery waste.
Dispose of plastic body and nozzles as plastic waste.
Dispose of metal components such as hanger & screws as metal waste.
All according to local regulations.
5. TECHNICAL DATA
Input (USB-C): 5V , 2A
Input (USB-A): 5V , 2A
Battery: 3.7V , 4000mAh
LED light: 4V , 3.5W
Inflation pressure: 2.5kPa - 4.5kPa
Degree of protection: The product is water resistant to IPX4
Class 3 appliance
DE: BEDIENUNGSANLEITUNG DE: BEDIENUNGSANLEITUNG
ROBENS CONIVAL 3IN1 PUMP
Lesen Sie dieses Handbuch vor der Verwendung des Produkts.
Bewahren Sie es zum späteren Nachlesen auf.
Inhalt:
1. Ein/Aus-Schalter für Pumpe
2. Ein-/Ausschalter für Laterne
3. Ladeanschlussabdeckung
4. Aufblasöffnung
5. Ablassöffnung
6. Laterne
7. Metallbügel
8. Batterieanzeige
9. USB-C-Ladeeingang
10. USB-A Powerbank-Ausgang
11. Solarpaneel
12. Ladekabel
13. USB-C-Stecker
14. USB-A Stecker
15. 6 Ventiladapter
WARNHINWEISE
1. Diese Pumpe ist zum Aufpumpen von aufblasbaren Gegenständen wie
Luftmatratzen, selbstaufblasbaren Liegematten usw. bestimmt und
ist nicht für einen Dauerbetrieb von mehr als 10 Minuten ausgelegt.
Längerer Betrieb kann zu Überhitzung führen und die Pumpe
beschädigen.
10 Minuten Dauerbetrieb nicht überschreiten!
Vor Wiederaufnahme des Aufpumpens eine Pause von
20 Minuten einlegen
2. Die Anweisungen auf dem aufzupumpenden Artikel genau befolgen.
Überschreiten Sie niemals den empfohlenen Druck. Berstende
Gegenstände können schwere Verletzungen verursachen.
