Schreder TFLEX LINE Installationsanleitung Seite 5

C
C1
C2
In case of unbalanced circuit:
02-47-274 | DOC-0019744 rev D | 02-2022
CONNECTORS AND INTERCONNECTIONS
1
2
3
3 PINS CONNECTOR C1
CONNECTOR PIN#
1
2
3
P1
P2
P3
P4
P5
5 PINS CONNECTOR C1
CONNECTOR PIN#
1
2
3
4
5
RED
ORANGE
www.schreder.com
WIRE COLOR
RED
BLACK
VIOLET
WIRE COLOR
RED
BLACK
ORANGE
YELLOW
VIOLET
(+) / BLACK (-) CIRCUIT 1
CIRCUIT 2
(+) / YELLOW (-)
CIRCUIT 1
CIRCUIT 2
UNBALANCED CIRCUIT
12 or 8 LEDS
4 LEDS
5
/8
