Touch Screen Display
The generator can only display parameters and waveform of one channel at a time. The picture below shows the interface when CH1 chooses
AM modulation of sine waveform. The information displayed may vary depending on the function selected.
The entire screen of the generator is a touch screen. You can use your finger or touch pen to control the instrument. Most functions and selections can be chosen
using the touch screen in a similar manner to the front panel keys and knob.
1. Waveform Display Area
Show the currently selected waveform of each channel. The key backlight will turn on when this area of the touch screen is clicked.
14
2
1
6
Figure 4 Touch Screen Display
3
5
