Fatal1ty Story
Who knew that at age 19, I would be a World Champion PC gamer. When I was 13, I
actually played competitive billiards in professional tournaments and won four or five
games off guys who played at the highest level. I actually thought of making a career
of it, but at that young age situations change rapidly. Because I've been blessed with
great hand-eye coordination and a grasp of mathematics (an important element in video
gaming) I gravitated to that activity.
GOING PRO
I started professional gaming in 1999 when I entered the CPL (Cyberathlete Professional
League) tournament in Dallas and won $4,000 for coming in third place. Emerging as one
of the top players in the United States, a company interested in sponsoring me fl ew me
to Sweden to compete against the top 12 players in the world. I won 18 straight games,
lost none, and took fi rst place, becoming the number one ranked Quake III player in the
world in the process. Two months later I followed that success by traveling to Dallas
and defending my title as the world's best Quake III player, winning the $40,000 grand
prize. From there I entered competitions all over the world, including Singapore, Korea,
Germany, Australia, Holland and Brazil in addition to Los Angeles, New York and St.
Louis.
WINNING STREAK
I was excited to showcase my true gaming skills when defending my title as CPL
Champion of the year at the CPL Winter 2001 because I would be competing in a totally
different first person shooter (fps) game, Alien vs. Predator II. I won that competition
and walked away with a new car. The next year I won the same title playing Unreal
Tournament 2003, becoming the only three-time CPL champion of the year. And I did it
playing a different game each year, something no one else has ever done and a feat of
which I am extremely proud.
At QuakeCon 2002, I faced off against my rival ZeRo4 in one of the most highly
anticipated matches of the year, winning in a 14 to (-1) killer victory. Competing at
Quakecon 2004, I became the World's 1st Doom3 Champion by defeating Daler in a
series of very challenging matches and earning $25,000 for the victory.
Since then Fatal1ty has traveled the globe to compete against the best in the world,
winning prizes and acclaim, including the 2005 CPL World Tour Championship in New
York City for a $150,000 fi rst place triumph. In August 2007, Johnathan was awarded the
fi rst ever Lifetime Achievement Award in the four year history of the eSports-Award for
"showing exceptional sportsmanship, taking part in shaping eSports into what it is today
and for being the prime representative of this young sport. He has become the fi gurehead
for eSports worldwide".
1
Fatal1ty P67 Performance Series Motherboard

Werbung

loading

Inhaltszusammenfassung für Fatal1ty P67 Performance Serie

  • Seite 1 Quakecon 2004, I became the World’s 1st Doom3 Champion by defeating Daler in a series of very challenging matches and earning $25,000 for the victory. Since then Fatal1ty has traveled the globe to compete against the best in the world, winning prizes and acclaim, including the 2005 CPL World Tour Championship in New York City for a $150,000 fi...
  • Seite 2 fl uid movement around the maps. My vision for Fatal1ty hardware is to allow gamers to focus on the game without worrying about their equipment, something I’ve preached since I began competing. I don’t want to worry about my equipment.
  • Seite 3 The Fatal1ty name, Fatal1ty logos and the Fatal1ty likeness are registered trade- marks of Fatal1ty, Inc., and are used under license. © 2011 Fatal1ty, Inc. All rights reserved. All other trademarks are the property of their respective owners. Fatal1ty website: www.fatal1ty.com...
  • Seite 4 Reset Switch (RSTBTN) PCI Express 2.0 x16 Slot (PCIE2, Red) SATA3 Connector (SATA3_1, Red) PCI Express 2.0 x1 Slot (PCIE1, Black) SATA3 Connector (SATA3_0, Red) Chassis Fan Connector (CHA_FAN3) SATA2 Connector (SATA2_3, Black) Power Fan Connector (PWR_FAN1) Fatal1ty P67 Performance Series Motherboard...
  • Seite 5 See the table below for connection details in accordance with the type of speaker you use. TABLE for Audio Output Connection Audio Output Channels Front Speaker Rear Speaker Central / Bass Side Speaker (No. 10) (No. 7) (No. 8) (No. 6) Fatal1ty P67 Performance Series Motherboard...
  • Seite 6 “ok”. Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are allowed to select “Realtek HDA Primary output” to use Rear Speaker, Central/Bass, and Front Speaker, or select “Realtek HDA Audio 2nd output” to use front panel audio. *** eSATA3 connector supports SATA Gen3 in cable 1M. Fatal1ty P67 Performance Series Motherboard...
  • Seite 7 1. Introduction Thank you for purchasing Fatal1ty P67 Performance Series motherboard, a reli- able motherboard produced under our consistently stringent quality control. It deliv- ers excellent performance with robust design conforming to our commitment to qual- ity and endurance. In this manual, chapter 1 and 2 contain introduction of the motherboard and step- by-step guide to the hardware installation.
  • Seite 8 - 1 x Coaxial SPDIF Out Port - 1 x Optical SPDIF Out Port - 5 x Ready-to-Use USB 2.0 Ports - 1 x Fatal1ty Mouse Port (USB 2.0) - 1 x eSATA3 Connector - 2 x Ready-to-Use USB 3.0 Ports...
  • Seite 9 - Drivers, Utilities, AntiVirus Software (Trial Version), Software Suite (CyberLink DVD Suite - OEM and Trial; Creative Sound Blaster X-Fi MB - Trial) Unique Feature - F-Stream (see CAUTION 6) - ASRock Instant Boot - ASRock Instant Flash (see CAUTION 7) Fatal1ty P67 Performance Series Motherboard...
  • Seite 10 Overclocking may affect your system stability, or even cause damage to the components and devices of your system. It should be done at your own risk and expense. We are not responsible for possible damage caused by overclocking. Fatal1ty P67 Performance Series Motherboard...
  • Seite 11 Your friends can then load the OC profi le in to their own system to get the same OC settings. In Mouse Polling mode, F-Stream allows you to adjust the mouse polling rate of the Fatal1ty Mouse port to add a professional level mouse confi guration. In IES (Intelligent Energy Saver) mode, the voltage regulator can reduce the number of output phases to improve effi...
  • Seite 12 Intel’s suggestion, the EuP ready power supply must meet the standard of 5v standby power effi ciency is higher than 50% under 100 mA current consumption. For EuP ready power supply selection, we recommend you checking with the power supply manufacturer for more details. Fatal1ty P67 Performance Series Motherboard...
  • Seite 13 CPU surface is unclean or if there is any bent pin on the socket. Do not force to insert the CPU into the socket if above situation is found. Other- wise, the CPU will be seriously damaged. Fatal1ty P67 Performance Series Motherboard...
  • Seite 14 Pin1 Pin1 alignment key orientation key notch 1155-Pin CPU 1155-Pin Socket For proper inserting, please ensure to match the two orientation key notches of the CPU with the two alignment keys of the socket. Fatal1ty P67 Performance Series Motherboard...
  • Seite 15 Please be noticed that this motherboard supports Combo Cooler Option (C.C.O.), which provides the fl exible option to adopt three dif- ferent CPU cooler types, Socket LGA 775, LGA 1155 and LGA 1156. The white throughholes are for Socket LGA 1155/1156 CPU fan. Fatal1ty P67 Performance Series Motherboard...
  • Seite 16 DDR3 slot; otherwise, this motherboard and DIMM may be dam- aged. Some DDR3 1GB double-sided DIMMs with 16 chips may not work on this motherboard. It is not recommended to install them on this motherboard. Fatal1ty P67 Performance Series Motherboard...
  • Seite 17 DIMM if you force the DIMM into the slot at incorrect orientation. Step 3. Firmly insert the DIMM into the slot until the retaining clips at both ends fully snap back in place and the DIMM is properly seated. Fatal1ty P67 Performance Series Motherboard...
  • Seite 18 Align the card connector with the slot and press fi rmly until the card is completely seated on the slot. Step 5. Fasten the card to the chassis with screws. Step 6. Replace the system cover. Fatal1ty P67 Performance Series Motherboard...
  • Seite 19 Please be noted that the password, date, time, user default profi le, 1394 GUID and MAC address will be cleared only if the CMOS battery is removed. The Clear CMOS Switch has the same function as the Clear CMOS jumper. Fatal1ty P67 Performance Series Motherboard...
  • Seite 20 SATA3_1 will not function. Serial ATA (SATA) Either end of the SATA data Data Cable cable can be connected to the SATA / SATAII / SATA3 hard (Optional) disk or the SATAII / SATA3 connector on this motherboard. Fatal1ty P67 Performance Series Motherboard...
  • Seite 21 2. If you use AC’97 audio panel, please install it to the front panel audio header as below: A. Connect Mic_IN (MIC) to MIC2_L. B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to OUT2_L. Fatal1ty P67 Performance Series Motherboard...
  • Seite 22 When connecting your chassis front panel module to this header, make sure the wire assignments and the pin assign-ments are matched correctly. Chassis Speaker Header Please connect the chassis speaker to this header. (4-pin SPEAKER 1) (see p.4 No. 13) Fatal1ty P67 Performance Series Motherboard...
  • Seite 23 Pin 1-3. Pin 1-3 Connected 3-Pin Fan Installation (3-pin CPU_FAN2) +12V CPU_FAN_SPEED (see p.4 No. 2) ATX Power Connector Please connect an ATX power supply to this connector. (24-pin ATXPWR1) (see p.4 No. 7) Fatal1ty P67 Performance Series Motherboard...
  • Seite 24 SPDIF audio output to HDMI (2-pin HDMI_SPDIF1) VGA card, allows the system to (see p.4 No. 33) SPDIFOUT connect HDMI Digital TV/ projector/LCD devices. Please connect the HDMI_SPDIF connector of HDMI VGA card to this header. Fatal1ty P67 Performance Series Motherboard...
  • Seite 25 (RSTBTN) Reset the system. (see p.4 No. 17) Clear CMOS Switch Clear CMOS Switch is a smart switch, allowing users to quickly (CLRCBTN) CMOS clear the CMOS values. (see p.5 No. 17) Fatal1ty P67 Performance Series Motherboard...
  • Seite 26 CPU post-memory initialization is started 0x33 CPU post-memory initialization. Cache initialization 0x34 CPU post-memory initialization. Application Processor(s) (AP) initialization 0x35 CPU post-memory initialization. Boot Strap Processor (BSP) selection 0x36 CPU post-memory initialization. System Management Mode (SMM) initialization Fatal1ty P67 Performance Series Motherboard...
  • Seite 27 Reserved for future AMI progress codes 0xF8 Recovery PPI is not available 0xF9 Recovery capsule is not found 0xFA Invalid recovery capsule 0xFB – 0xFF Reserved for future AMI error codes 0x60 DXE Core is started 0x61 NVRAM initialization Fatal1ty P67 Performance Series Motherboard...
  • Seite 28 USB Detect 0x9D USB Enable 0x9E – 0x9F Reserved for future AMI codes 0xA0 IDE initialization is started 0xA1 IDE Reset 0xA2 IDE Detect 0xA3 IDE Enable 0xA4 SCSI initialization is started 0xA5 SCSI Reset Fatal1ty P67 Performance Series Motherboard...
  • Seite 29 No Console Input Devices are found 0xD8 Invalid password 0xD9 Error loading Boot Option (LoadImage returned error) 0xDA Boot Option is failed (StartImage returned error) 0xDB Flash update is failed 0xDC Reset protocol is not available Fatal1ty P67 Performance Series Motherboard...
  • Seite 30 STEP 1: Set up UEFI. A. Enter UEFI SETUP UTILITY Advanced screen Storage Confi guration. B. Set the option “SATA Mode” to [IDE]. ® STEP 2: Install Windows XP / XP 64-bit OS on your system. Fatal1ty P67 Performance Series Motherboard...
  • Seite 31 A. Enter UEFI SETUP UTILITY Advanced screen Storage Confi guration. B. Set the option “SATA Mode” to [AHCI]. ® STEP 2: Install Windows 7 / 7 64-bit / Vista / Vista 64-bit OS on your system. Fatal1ty P67 Performance Series Motherboard...
  • Seite 32 It will display the Main Menu automatically if “AUTORUN” is enabled in your computer. If the Main Menu does not appear automatically, locate and double-click on the fi le “ASSETUP.EXE” from the BIN folder in the Support CD to display the menus. Fatal1ty P67 Performance Series Motherboard...
  • Seite 33 1. Einführung Wir danken Ihnen für den Kauf des Fatal1ty P67 Performance Series Mother- board, ein zuverlässiges Produkt, welches unter den ständigen, strengen Qualitäts- kontrollen von gefertigt wurde. Es bietet Ihnen exzellente Leistung und robustes De- sign, gemäß der Verpfl ichtung von zu Qualität und Halbarkeit. Diese Schnellinstalla- tionsanleitung führt in das Motherboard und die schrittweise Installation ein.
  • Seite 34 Rückseite - 1 x PS/2-Tastaturanschluss - 1 x Koaxial-SPDIF-Ausgang - 1 x optischer SPDIF-Ausgang - 5 x Standard-USB 2.0-Anschlüsse - 1 x Fatal1ty Mausanschluss (USB 2.0) - 1 x eSATA3-Anschluss - 2 x Standard-USB 3.0-Anschlüsse Fatal1ty P67 Performance Series Motherboard...
  • Seite 35 BIOS - 64Mb AMI BIOS - AMIs Legal BIOS UEFI mit GUI-Unterstützung - Unterstützung für “Plug and Play” - ACPI 1.1-Weckfunktionen - JumperFree-Übertaktungstechnologie - SMBIOS 2.3.1 - DRAM, PCH, CPU PLL, VTT, VCSA Stromspannung Multianpassung Fatal1ty P67 Performance Series Motherboard...
  • Seite 36 Stabilität Ihres Systems auswirken oder sogar Komponenten und Geräte Ihres Systems beschädigen. Es geschieht dann auf eigene Gefahr und auf Ihre Kosten. Wir übernehmen keine Verantwortung für mögliche Schäden, die aufgrund von Overclocking verursacht wurden. Fatal1ty P67 Performance Series Motherboard...
  • Seite 37 Sie Ihr BIOS mit nur wenigen Klickvorgän- gen ohne Bereitstellung einer zusätzlichen Diskette oder eines ande- ren komplizierten Flash-Programms aktualisieren. Achten Sie darauf, dass das USB-Flash-Laufwerk oder die Festplatte das Dateisystem FAT32/16/12 benutzen muss. Fatal1ty P67 Performance Series Motherboard...
  • Seite 38 14. Die Combo-Kühleroption bietet die fl exible Möglichkeit zur Aufnahme von drei verschiedenen CPU-Kühlertypen, Socket LGA 775, LGA 1155 und LGA 1156. Beachten Sie bitte, dass nicht alle 775 und 1156 CPU-Lüfter verwen- det werden können. Fatal1ty P67 Performance Series Motherboard...
  • Seite 39 Stromversorgung dem Standard entsprechen, was bedeutet, dass bei einem Stromverbrauch von 100 mA die 5-Volt-Standby-Energieeffi zienz höher als 50% sein sollte. Für die Wahl einer EuP-fähigen Stromversorgung empfehlen wir Ihnen, weitere Details beim Hersteller der Stromversorgung abzufragen. Fatal1ty P67 Performance Series Motherboard...
  • Seite 40 Bevor Sie die 1155-Pin CPU in den Sockel sitzen, prüfen Sie bitte, ob die CPU-Oberfl äche sauber ist und keine der Kontakte verbogen sind. Setzen Sie die CPU nicht mit Gewalt in den Sockel, dies kann die CPU schwer beschädigen. Fatal1ty P67 Performance Series Motherboard...
  • Seite 41 Schritt 3-2. Halten Sie das Teil mit dem IHS (Integrated Heat Sink – integ- rierter Kühlkörper) nach oben. Suchen Sie Pin 1 und die zwei Orientierungseinkerbungen. Ausrichtungsmarkierung Orientierungskerbe Pin1 Pin1 Ausrichtungsmarkierung Orientierungskerbe 1155-Pin Sockel 1155-Pin CPU Fatal1ty P67 Performance Series Motherboard...
  • Seite 42 Schritt 4-1. Drehen Sie die Ladeplatte auf den Kühlkörper (IHS). Schritt 4-2. Drücken Sie leicht auf die Lade- platte und schließen Sie den Ladehebel. Schritt 4-3. Sichern Sie Ladehebel und Ladeplatte mithilfe des Hebelver- schlusses. Fatal1ty P67 Performance Series Motherboard...
  • Seite 43 Beachten Sie bitte, dass dieses Motherboard die Combo-Kühlerop- tion unterstützt, die eine fl exible Möglichkeit zur Aufnahme von drei verschiedenen CPU-Kühlertypen, Socket LGA 775, LGA 1155 und LGA 1156, bietet. Das weiße Durchgangsloch ist für den CPU-Lüfter im Socket LGA 1155/1156 vorgesehen. Fatal1ty P67 Performance Series Motherboard...
  • Seite 44 2.3 Installation der Speichermodule (DIMM) Die Motherboards Fatal1ty P67 Performance Series bieten vier 240-pol. DDR3 (Double Data Rate 3) DIMM-Steckplätze und unterstützen die Dual-Kanal- Speichertechnologie. Für die Dual-Kanalkonfi guration dürfen Sie nur identische (gleiche Marke, Geschwindigkeit, Größe und gleicher Chiptyp) DDR3 DIMM-Paare in den Steckplätzen gleicher Farbe installieren.
  • Seite 45 Steckplätze zu zwingen, führt dies zu dauerhaften Schäden am Mainboard und am DIMM-Modul. Schritt 3: Drücken Sie die DIMM-Module fest in die Steckplätze, so dass die Halteklammern an beiden Enden des Moduls einschnappen und das DIMM-Modul fest an Ort und Stelle sitzt. Fatal1ty P67 Performance Series Motherboard...
  • Seite 46 Erweiterungssteckplätze (PCI-Steckplätze und PCI Express-Steckplätze) Es gibt einen 3 PCI-Steckplätze und 4 PCI Express-Steckplätze am Fatal1ty P67 Performance Series Motherboard. PCI-Slots: PCI-Slots werden zur Installation von Erweiterungskarten mit dem 32bit PCI-Interface genutzt. PCI Express-Slots: PCIE1 / PCIE3 / PCIE4 (PCIE x1-Steckplatz; Schwarz) wird für PCI Express-Karten mit x1 Lane-Breite-Karten verwendet, z.B.
  • Seite 47 CMOS-Löschung herunter. Bitte beachten Sie, dass Kennwort, Datum, Uhrzeit, benutzerdefi niertes Profi l, 1394 GUID und MAC-Adresse nur gelöscht werden, wenn die CMOS-Batterie entfernt wird. Der CMOS löschen-Schalter hat dieselbe Funktion wie der CMOS löschen-Jumper. Fatal1ty P67 Performance Series Motherboard...
  • Seite 48 Seriell-ATA3-Anschlüsse Diese zwei Serial ATA3- (SATA3-)Verbínder (SATA3_0: siehe S.4 - No. 19) unterstützten SATA-Datenkabel (SATA3_1: siehe S.4 - No. 18) SATA3_1 SATA3_0 für interne Massenspeichergeräte. Die aktuelle SATA3- Schnittstelle ermöglicht eine Datenübertragungsrate bis 6,0 Gb/s. Fatal1ty P67 Performance Series Motherboard...
  • Seite 49 Dieses Interface zu einem PRESENCE# MIC_RET der Gehäusevorderseite Audio-Panel auf der Vorder OUT_RET seite Ihres Gehäuses, (9-Pin HD_AUDIO1) ermöglicht Ihnen eine bequeme (siehe S.4 - No. 32) OUT2_L Anschlussmöglichkeit und J_SENSE OUT2_R Kontrolle über Audio-Geräte. MIC2_R MIC2_L Fatal1ty P67 Performance Series Motherboard...
  • Seite 50 Gehäuses. Die LED leuchtet, wenn das System in Betrieb ist. Die LED blinkt, wenn sich das System im Ruhezustand S1 befi ndet. Die LED schaltet sich aus, wenn sich das System in den Modi S3/S4 befi ndet oder ausgeschaltet ist (S5). Fatal1ty P67 Performance Series Motherboard...
  • Seite 51 Draht an den +12V CHA_FAN_SPEED Schutzleiterstift angeschlossen wird. (3-pin CHA_FAN2) CHA_FAN2_PWR (siehe S.4 - No. 10) CHA_FAN_SPEED (3-pin CHA_FAN3) (siehe S.4 - No. 39) (3-pin PWR_FAN1) (siehe S.4 - No. 40) PWR_FAN_SPEED +12V Fatal1ty P67 Performance Series Motherboard...
  • Seite 52 Verfügung stellt, kann sie noch arbeiten, wenn Sie einen traditionellen 4-Pin ATX 12V Energieversorgung adoptieren. Um die 4-Pin ATX Energieversorgung zu verwenden, stecken Sie bitte Ihre Energieversorgung zusammen mit dem Pin 1 und Pin 5 ein. Installation der 4-Pin ATX 12V Energieversorgung Fatal1ty P67 Performance Series Motherboard...
  • Seite 53 Audioausgang für eine HDMI- (siehe S.4 - No. 33) SPDIFOUT VGA-Karte zur Verfügung und ermöglicht den Anschluss von HDMI-Digitalgeräten wie Fernsehgeräten, Projektoren, LCD-Geräten an das System. Bitte verbinden Sie den HDMI_SPDIF-Anschluss der HDMI-VGA-Karte mit diesem Anschluss. Fatal1ty P67 Performance Series Motherboard...
  • Seite 54 Reset Benutzer das System schnell (siehe S.4 - No. 17) zurücksetzen können. CMOS löschen-Schalter Der CMOS löschen-Schalter ist ein Schnellschalter, mit dem (CLRCBTN) CMOS Benutzer die CMOS-Werte (siehe S.5 - No. 17) schnell löschen können. Fatal1ty P67 Performance Series Motherboard...
  • Seite 55 A. Rufen Sie das UEFI SETUP UTILITY auf, wählen Sie den „Advanced“- Bildschirm (Erweitert), dann „SATA Confi guration“. B. Stellen Sie “SATA Mode” auf [IDE]. ® SCHRITT 2: Installieren Sie Windows XP / XP 64-Bit in Ihrem System. Fatal1ty P67 Performance Series Motherboard...
  • Seite 56 A. Rufen Sie das UEFI SETUP UTILITY auf, wählen Sie den „Advanced“- Bildschirm (Erweitert), dann „SATA Confi guration“. B. Stellen Sie “SATA Mode” auf [AHCI]. ® SCHRITT 2: Installieren Sie Windows 7 / 7 64-Bit / Vista / Vista 64-Bit in Ihrem System. Fatal1ty P67 Performance Series Motherboard...
  • Seite 57 ASSETUP.EXE im BIN-Verzeichnis der Support-CD, um die Menüs aufzurufen. Das Setup-Programm soll es Ihnen so leicht wie möglich machen. Es ist menüges- teuert, d.h. Sie können in den verschiedenen Untermenüs Ihre Auswahl treffen und die Programme werden dann automatisch installiert. Fatal1ty P67 Performance Series Motherboard...
  • Seite 58 1. Introduction Merci pour votre achat d’une carte mère Fatal1ty P67 Performance Series, une carte mère très fi able produite selon les critères de qualité rigoureux de. Elle of- fre des performances excellentes et une conception robuste conformément à l’engagement sur la qualité et la fi abilité au long terme.
  • Seite 59 - 1 x port souris PS/2 - 1 x port clavier PS/2 - 1 x Port de sortie coaxial SPDIF - 1 x Port de sortie optique SPDIF - 5 x ports USB 2.0 par défaut Fatal1ty P67 Performance Series Motherboard...
  • Seite 60 - 1 x Fatal1ty port souris (USB 2.0) - 1 x Connecteur eSATA3 - 2 x ports USB 3.0 par défaut - 1 x port LAN RJ-45 avec LED (ACT/LED CLIGNOTANTE et LED VITESSE) - 1 x interrupteur d’effacement du CMOS avec LED - Prise HD Audio: Haut-parleur latéral / Haut-parleur arrière /...
  • Seite 61 - Microsoft Windows 7 / 7 64-bit / Vista / Vista 64-bit / XP / XP 64-bit Certifi cations - FCC, CE, WHQL - Prêt pour ErP/EuP (alimentation Prêt pour ErP/EuP requise) (voir ATTENTION 15) Fatal1ty P67 Performance Series Motherboard...
  • Seite 62 CPU ne sont pas utilisées, sans diminuer les performances de l’ordinateur. Fatal1ty P67 Performance Series Motherboard...
  • Seite 63 12. Même si cette carte mère offre un contrôle sans souci, il n’est pas re- commandé d’y appliquer un over clocking. Des fréquences de bus CPU autres que celles recommandées risquent de rendre le système instable ou d’endommager le CPU et la carte mère. Fatal1ty P67 Performance Series Motherboard...
  • Seite 64 électrique de 5v en mode de veille doit être supérieure à 50% pour 100 mA de consommation de courant. Pour choisir une alimentation électrique conforme à la norme EuP, nous vous recommandons de con- sulter votre fournisseur de courant pour plus de détails. Fatal1ty P67 Performance Series Motherboard...
  • Seite 65 Si c’est le cas, ne forcez pas pour insérer le processeur dans le socket. Sinon, le processeur sera gravement endommagé. Fatal1ty P67 Performance Series Motherboard...
  • Seite 66 Etape 3-2. Orientez le paquet avec le dissipa- teur thermique intégré (IHS) vers le haut. Repérez la broche 1 et les deux encoches d’orientation. Encoche d’orientation Détrompeur broche 1 broche 1 Détrompeur Socket 1155 broches Encoche d’orientation Processeur 1155 broches Fatal1ty P67 Performance Series Motherboard...
  • Seite 67 L’exemple ci-dessous illustre l’installation du dissipateur thermique pour un proces- seur 1155 broches. Etape 1. Appliquez le matériau d’interface thermique (Appliquez le matériau au centre de IHS sur la surface du socket. d’interface thermique) Apply Thermal Interface Material Fatal1ty P67 Performance Series Motherboard...
  • Seite 68 Cooler Option (C.C.O.), qui offre un choix fl exible pour adopter trois types différents de refroidisseurs de CPU, les sockets LGA 775, LGA 1155 et LGA 1156. Les trous traversant blancs sont pour le ventila- teur de CPU au socket LGA 1155/1156. Fatal1ty P67 Performance Series Motherboard...
  • Seite 69 2.3 Installation des modules m émoire [DIMM] La carte mère Fatal1ty P67 Performance Series dispose de quatre emplacements DIMM DDR3 (Double Data Rate 3) de 240-broches, et supporte la Technologie de Mémoire à Canal Double. Pour effectuer une confi guration à canal double, vous devez toujours installer des paires de DIMM DDR3 identiques (de la même marque,...
  • Seite 70 DIMM. Etape 3. Insérez fermement le module DIMM dans son emplacement jusqu’à ce que les clips de maintien situés aux deux extrémités se ferment complètement et que le module DIMM soit inséré correctement. Fatal1ty P67 Performance Series Motherboard...
  • Seite 71 Slot d’extension (Slots PCI et Slots PCI Express) Il y a 3 ports PCI et 4 ports PCI Express sur la carte mère Fatal1ty P67 Perfor- mance Series. Slots PCI: Les slots PCI sont utilisés pour installer des cartes d’extension dotées d’une interface PCI 32 bits.
  • Seite 72 CMOS. Veuillez noter que le mot de passe, la date, l’heure, le profi l par défaut de l’utilisateur, 1394 GUID et l’adresse MAC seront effacés seulement si la batterie du CMOS est enlevée. Le commutateur Effacer CMOS présente la même fonction que le cavalier Effacer CMOS. Fatal1ty P67 Performance Series Motherboard...
  • Seite 73 (SATA3_0: voir p.4 No. 19) charge les câbles SATA pour (SATA3_1: voir p.4 No. 18) SATA3_1 SATA3_0 les périphériques de stockage internes. L’interface SATA3 actuelle permet des taux transferts de données pouvant aller jusqu’à 6,0 Gb/s. Fatal1ty P67 Performance Series Motherboard...
  • Seite 74 C’est une interface pour PRESENCE# MIC_RET un câble avant audio en façade (HD_AUDIO1 br. 9) OUT_RET qui permet le branchement et (voir p.4 No. 32) le contrôle commodes de OUT2_L périphériques audio. J_SENSE OUT2_R MIC2_R MIC2_L Fatal1ty P67 Performance Series Motherboard...
  • Seite 75 Ce voyant DEL est allumé lorsque le système est en marche. Le voyant DEL clignote lorsque le système est en mode veille S1. Le voyant DEL est éteint lorsque le système est en mode veille S3/ S4 ou lorsqu’il est éteint (S5). Fatal1ty P67 Performance Series Motherboard...
  • Seite 76 Veuillez connecter le câble de FAN_SPEED_CONTROL CPU_FAN_SPEED de l’UC ventilateur d’UC sur ce +12V connecteur et brancher le fi l (CPU_FAN1 br. 4) noir sur la broche de terre. (voir p.4 No. 3) 1 2 3 4 Fatal1ty P67 Performance Series Motherboard...
  • Seite 77 1 et la broche 5. 4-Installation d’alimentation à 4 broches ATX 12V En-tête de port COM Cette en-tête de port COM est utilisée pour prendre en charge (COM1 br.9) un module de port COM. (voir p.4 No. 31) Fatal1ty P67 Performance Series Motherboard...
  • Seite 78 à l’utilisateur de réinitialiser rapidement le système. Interrupteur d’effacement de CMOS L’interrupteur d’effacement de (CLRCBTN) CMOS est un interrupteur rapide (voir p.5 No. 17) qui permet à l’utilisateur d’effacer CMOS rapidement les valeurs du CMOS. Fatal1ty P67 Performance Series Motherboard...
