QuanSheng UV-K5 Benutzerhandbuch Seite 11

W/N 10 Channel Bandwidth (0:WIDE 1:NARROW
SCR 11 Encrypted Communication (OFF, 1-10: 1 to 10 types of
scrambling frequency.)
BCL 12 Busy Channel Lock (OFF,ON
MEM-CH 13 Channel Save (Choose the channel by Up/Down Key and
Number Key, press MENU key to Save the channel.)
SAVE 14 Battery Save (OFF/1:1/1:2/1:3/1:4)
The rate between active time and sleep time.
VOX 15 VOX Setting (OFF: turn off VOX, 1-10: 1 to 10 grade.)
ABR 16 Auto Backlight (OFF: turn off Backlight; 1-5: turn off Backlight in
1-5 seconds)
TDR 17 Dual-watch On/Off (OFF: Close, CHAN_A: Default TX Channel
is A channel, CHAN_B Default TX Channel is B channel.)
WX 18 Cross-Band Receiving/Transmitting (OFF: Close, CHAN_A: TX
Channel is A channel, CHAN_B TX Channel is B channel.)
BEEP 19 BEEP Control (OFF, ON)
TOT 20 Time-Out-Timer (1-10min)
VOICE 21 Voice Prompt (OFF, CHI: Chinese, ENG: English)
SC-REV 22 Scan Resume Mode (TO: Resume scan after 5 seconds` pause;
CO: Resume scan after signal disappear; SE: After receive the
signal, stop scan.)
MDF 23 Channel Display Mode(FREQ: Display frequency, CH: Display
channel No., NAME: Display channel name)
AUTOLK 24 Auto Keypad Lock (OFF,ON
S-ADD1 25 Whether to participate in list 1 scanning (OFF: not participating,
ON: participation)
S-ADD2 26 Whether to participate in list 2 scanning (OFF: not participating,
ON: participation)
STE 27 Tail Tone Elimination (OFF,ON
RP-STE 28 Repeater Tail Tone Elimination (OFF,ON
MIC 29 MIC Sensitivity (0-4: 0-4 level)
1-CALL 30 One Key Call Channel (Select the channel through the Up/Down
keys and the Number keys)
S-LIST 31 Channel Scan List Select (LIST 1: Scan list 1; LIST 2: Scan list 2
SLIST1 32 Channel Scan List 1 Configuration
SLIST2 33 Channel Scan List 2 Configuration
AL-MOD 34 Alarm Mode(SITE: local alarm; TONE: Distant + local alarm)
ANI-ID 35 ANI-ID, DTMF communication radio ID
UPCODE 36 DTMF UP CODE
DWCODE 37 DTMF DOWN CODE
D-ST 38 DTMF Side Tone Switch (OFF, ON
D-RSP 39 DTMF Decoding Response (NULL: Close, Ring: Local ringing,
REPLY: reply response, both: local ringing +reply response)
D-HOLD 40 DTMF Auto Reset Time (5s-60s
D-PRE 41 DTMF pre-load time(30-990ms)
PTT-ID 42 DTMF PTT-ID TX Mode (OFF: Close, BOT: Press PTT to send
UP CODE, EOT: Release PTT to send DOWN CODE, BOTH:
Press or release PTT to send.
D-DCD 43 DTMF decoding enable signal (OFF, ON)
D-LIST 44 DTMF Contact List (Choose the contact by Up/Down Key and
Number Key, press MENU key to select the contact and call
directly.)
0-1
0-10
0-1
0-4
0-10
0-5
0-2
0-2
0-1
1-10
0-2
0-2
0-2
0-1
0-1
0-1
0-1
0-1
0-4
1-2
0-1
0-1
0-3
5-60
3-99
0-3
0-1
1-16
