STEINEL PROFESSIONAL IS 3360 Applikationsbeschreibung Seite 6

Obj Object name
12 Switch light 2 output
This object is only visible if the "Number of Light Outputs" parameter is set
to "2" in the "Light Output" parameter window. This object must be linked
with the switching object of the actuator used for switching the lighting ON
and OFF.
13 Light 2 output dimming level
This object is only visible if the "Number of Light Outputs" parameter is set
to "2" in the "Light Output" parameter window, or if the "Basic Illumination"
parameter is set to "active".
This object must be linked with the dimming-level object of the actuator used
for dimming lighting to the level being received. The group address linked
with this object is used for sending the dimming value via bus to the actuator,
with it also being possible to request this from the detector.
14 Disable light output
This object is only visible if the "Disable Light Output" parameter is not set
to "No" in the "Light Output" parameter window. The "Disable Light Output"
parameter is also used for selecting whether disabling is to take place on
receiving a value of "1" or on receiving a value of "0".
When the output is disabled, the detector does not automatically send any
telegrams for operating or dimming lighting. Telegrams received by the sen-
sor via the "Switch Light ON/OFF Input" object are sent to the "Switch Light
ON/OFF Output" object.
15 Light output disabling status
This object is only visible if the "Disable Light Output" parameter is not set to
"No" in the "Light Output" parameter window.
The group address linked with this object is used for automatically sending
the output's disabling status via bus after any change; the disabling status
can be requested from the detector at any time.
16 Switch light 1 input
This object is always available. It must be linked with the switching object of
the button the user can switch lighting ON and OFF with.
If a telegram is received via this object, lighting will be operated in line with
the telegram's value and the "Action at Light Input" parameter in the "Light
Output" parameter window.
17 Dim light 1 input
This object is only visible if the "Constant-Lighting Control" parameter is set
to "Yes" in the "Light Output" parameter window. If a telegram is received via
this object, and depending on the "Light-Level Control for Dim Light x Input"
parameter setting, light-level control is either disabled with the relevant light-
ing group being dimmed, or light-level control is not disabled and the light-
level control setting is increased or decreased accordingly, automatically re-
sulting in a lighter or darker dimming of the lighting. If the detector establishes
that nobody remains in the room, the altered light-level setting is returned to
its original value and the lighting is switched OFF.
18 Light 1 input dimming level
This object is only visible if the "Telegram Type" parameter is set to "Dim-
ming Level" in the "Light Output" parameter window. It must be linked with
the dimming-level object of the button the user can switch lighting ON and
OFF with.
If a telegram is received via this object, lighting will be operated in line with
the telegram's value and the "Action at Light Input" parameter in the "Light
Output" parameter window.
19 Switch light 2 input
This object is only visible if the "Number of Light Outputs" parameter is set
to "2" in the "Light Output" parameter window. It must be linked with the
switching object of the button the user can switch lighting ON and OFF with.
If a telegram is received via this object, lighting will be operated in line with
the telegram's value and the "Action at Light Input" parameter in the "Light
Output" parameter window.
Function DP type Flag
1,001
ON/OFF CRT
(1 bit)
5,001
0...100% CRT
(8 bits)
1,001
ON/OFF CWT
(1 bit)
1,001
ON/OFF CRT
(1 bit)
1,001
ON/OFF CWT
(1 bit)
brighter / 3,007
CWT
darker (4 bits)
5,001
0...100% CWT
(8 bits)
1,001
ON/OFF CWT
(1 bit)
Application description for 3000-series sensors
Obj Object name
20 Dim light 2 input
This object is only visible if the "Number of Light Outputs" parameter is set
to "2" in the "Light Output" parameter window and the "Constant-Lighting
Control" parameter is set to "Yes".
If a telegram is received via this object, and depending on the "Light-Level
Control for Dim Light x Input" parameter setting, light-level control is either
disabled with the relevant lighting group being dimmed, or light-level control
is not disabled and the light-level control setting is increased or decreased
accordingly, automatically resulting in a lighter or darker dimming of the light-
ing. If the detector establishes that nobody remains in the room, the altered
light-level setting is returned to its original value and the lighting is switched
OFF.
21 Light 2 input dimming level
This object is only visible if the "Number of Light Outputs" param-
eter is set to "2" in the "Light Output" parameter window and the
"Telegram Type" parameter is set to "Dimming Level". It must be linked
with the dimming-level object of the button the user can switch lighting ON
and OFF with.
If a telegram is received via this object, lighting will be operated in line with
the telegram's value and the "Action at Light Input" parameter in the "Light
Output" parameter window.
Time factor for
22
light stay-ON time
This object is always available. The group address linked with this object is
used for receiving the stay-ON time (in minutes) via bus, this being the time
for which lighting is to remain switched ON after the last person leaves the
detection zone. Any value received outside the permissible range of 1 to 255
is rejected. This object can also be used at any time for requesting the time
lighting is currently to stay ON for, also after making a change via ETS or IR
remote control.
Switch light 1 basic
23
illumination output
This object is only visible if the "Light 1 Basic Illumination via" parameter
is set to "switching object" in the "Basic Illumination" parameter window.
This object must be linked with the switching object of the actuator used for
switching basic illumination ON and OFF. The group address linked with this
object is used for sending the switching command via bus to the actuator,
with it also being possible to request the switching status from the detector.
Switch light 2 basic
24
illumination output
This object is only visible if the "Light 2 Basic Illumination via" parameter
is set to "switching object" in the "Basic Illumination" parameter window.
This object must be linked with the switching object of the actuator used for
switching basic illumination ON and OFF. The group address linked with this
object is used for sending the switching command via bus to the actuator,
with it also being possible to request the switching status from the detector.
25 Twilight sensor input
This object is only visible if the "Basic Illumination ON" parameter is set to
"Yes" in the "Basic Illumination" parameter window. The group address linked
with this object can be used via the bus for changing the basic light-level
threshold (in lux) at which basic illumination is activated if not met and at
which basic illumination is switched OFF again if significantly exceeded. Any
value received outside the permissible range of 2 to 1000 lux is rejected. This
object can also be used for requesting the current threshold value at any
time, also after making a change via ETS or IR remote control.
26 Basic light-level threshold
This object is only visible if the "Basic Illumination ON" parameter is set to
"Yes" in the "Basic Illumination" parameter window. The group address linked
with this object can be used via the bus for changing the basic light-level
threshold (in lux) at which basic illumination is activated if not met and at
which basic illumination is switched OFF again if significantly exceeded. Any
value received outside the permissible range of 2 to 1000 lux is rejected. This
object can also be used for requesting the current threshold value at any
time, also after making a change via ETS or IR remote control.
- 6 -
Function DP type Flag
brighter/ 3,007
CWT
darker (4 bits)
5,001
0...100% CWT
(8 bits)
5,005
1...255 CRWT
(8 bits)
1,001
ON/OFF CRT
(1 bit)
1,001
ON/OFF CRT
(1 bit)
9,004
2 to 1000 lux CWT
(16 bits)
9,004
2 to 1000 lux CRWT
(16 bits)
