WHAT'S IN THE BOX
x1
Main Pole
x1
B-Rod
x1
C-Rod
x1
D-Rod
x2
E-Rod
x8
1500mm
Channel Steel
x1
x1
300mm
150mm
Linear Actuator
Linear Actuator
x1
x1
Wind Speed
Sunlight
Sensor
Sensor
x2
x8
U-Shaped
M8*20
Connector
Socket Cap
x8
x8
M10*20
Socket Cap
U-Shaped
Locker
x18
M8*40
Socket Cap
x4
Linear Actuator
Stand
x12
M10*60
Socket Cap
x4
x12
M10*70
Solar Panel
Socket Cap
Side Clamp
x8
M10*100
Socket Cap
x6
Solar Panel
x1
Middle Clamp
M14*110
Socket Cap
x1
x2
Sunlight sensor
M6*12
Stand
Hex Cap
x1
Solar tracker
Controller
would be shown as a simplified
figure. Please refer to the material
x1
Compass
box on the top of every step.
x1
M10*40
Hex Cap
x4
M4*16
Hex Cap
x8
Expansion
Bolt
x6
Latch
x2
Flange Nut
x34
Hex Nut
x62
Washer
x34
Elastic
Washer
For the convenience
of display, some of the bolts
