Overview Magnum; Magnum In Detail - Rösle BBQ Station Magnum G3 Bedienungsanleitung

Overview Magnum

1
17
16
15
14
13
12
11
10
Lid thermometer
1
Lid with glass insert
2
Back Burner with control knob,
3
Modell Pro G3 / Pro G4, Pro G4-S
Primezone with cast iron grate (adjustable
4
height), Modell Pro G3 / Pro G4, Pro G4-S
5 Drip tray, model Pro G3 / Pro G4, Pro G4-S
Control knob for main burner (with Jet
Flame ignition system) with lighting (see
6
detailed image G3 / G4, Pro G3 / Pro G4, Pro
G4-S)
7 Castors with brake
8 Gas cylinder with holder and gas regulator
52
9

Magnum in detail

9 Storage space
10 Power supply unit for interior lights
11 Holder for waste bag
Igniter button Back burner, Primezone or
12 side burner (G3, G4) with battery compart-
ment
13 Switch for lights
14 Side burner
Grate with FatDrip system and
15
discharge channel
16 Warming rack
17 Interior lights in cooking area
2
3
4
5
6
8 7
Fig.: Magnum Pro G4-S
