Parts Diagram

Parts List
Item #
1
2
3
4
5
6
Assembly
6
Part Name
Disc Block
Wheel Retainer
2" Caster
ST5.5x17 Screw
M6x30 Bolt
M6 Lock Nut
5
QTY Illustration / Part #
8
TH11-000-0001
4
TH11-000-0002
4 TH11-000-0003
TH11-090-0001
40
8
TH11-090-0002
8
TH11-090-0003
(English)
4
2
1
3
