Quick guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your product on www.whirlpool.eu/register
CONTROL PANEL
1 Programme selection knob
2
On/Off button
3 Start/Pause button
Options buttons
4 FreshCare+
5 Cycle End Signal
6 Rapid
7 Cycle Options (hold for Settings)
8
Dryness Level
9 Timed Drying
10 Start Delay
Navigation buttons and Key Lock
11 UP
12 DOWN
13 CONFIRM (hold for Key Lock)
INDICATORS
Cycle phase:
Drying -
Empty water tank -
Refer to Troubleshooting section:
FIRST TIME USE
When starting the appliance the first time, the control panel will
automatically show the set language menu. The UP and DOWN
buttons are used to show the languages available in the
machine. Press the button to confirm. The machine cannot be
used without having selected the language.
Make sure that the water tank is correctly inserted.
The dryer must be installed in a room with a temperature
ranging between 5°C and 35°C to ensure proper operation.
Before using the dryer make sure it has been in an upright
position for at least 6 hours.
Should you wish to change the opening side of the door, please
contact our After-sales Service. (See phone number in the
warranty booklet).
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying cycle.
- remember to clean your filters after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions on
clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door filter. Do not load items that
are dripping wet. Do not tumble dry large, very bulky items.
3. Close the door.
4. Press the "On/Off" button.
5. Select the most suitable programme for the type of fabric in that
load.
6. Select the options, if necessary.
7. Press the "Start/Pause" button to begin drying.
8. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Pull the load out
immediately to prevent the formation of creases on laundry.
Policies, standard documentation, ordering of spare parts and additional product information can be
9. Turn the machine off by pressing the "On/Off" button, open the
found by:
door and pull the clothing out. If the machine is not switched off
• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com
manually, after about a quarter of an hour from the end of the
• Using QR Code
cycle , the appliance turns off automatically to save energy.
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
Note that some programme/option accords with "Crease Care"
contacting our After-sales Service, please state the codes provided on your product's identification plate.
system. This means that for some hours, after the end of the
drying cycle, the drum rotates at regular intervals to prevent the
formation of creases.
In case of power failure, it is necessary to press the "Start/Pause"
button to restart the cycle.
1
Cool Down
Clean secondary filter -
Failure call After-sales Service -
Before using the appliance carefully read the Safety
Instruction.
5
6
7
Clogged door filters -
Demo Mode
DEMO
Eco Monitor
This indicator shows the energy consumption level according to
the programme and the options set. The consumption is
proportional to the lines on the display, by the ecomonitor icon.
OPENING THE DOOR DURING THE CYCLE
Laundry can be checked while the drying cycle runs and any
garments already dry can be removed, while drying continues for
the remaining items. After closing the door, press the "Start/Pause"
button to resume machine operation.
Keep the door closed until the cycle end to save time and energy.
NAVIGATION
The "UP" and "DOWN" buttons are used to navigate the available
menus.
• Press the button to confirm the selection.
• Press the option button at the
display, to return to the previous screen.
If no selection is confirmed, after about 10 seconds, the display
return to the main screen.
SETTINGS
To access the Settings menu, press and hold the relevant button for a
few seconds.
• Set language shows the available languages on the display.
• Sounds allows to enable or disable the sounds (some sounds, as
warnings, will remain active anyway).
• Brightness allows to modify the display brightness.
• Factory Default allows to reset the default settings. After having
selected the setting, press and hold the
seconds.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the fi rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
1:35
SYNTHETICS
-:--
-:--
8 9 10
Autoclean - Eco Monitor
symbol, where present on the
EN
2
11
12
4
13
3
button for a few
