3.4 Safety Information
1. Follow all instructions and guidelines.
2. Use only standard battery cells of the type CR2032.
3. Ensure that the battery cover is properly sealed to avoid debris and moisture penetration.
4. The battery should be removed in the following cases:
• Water or other liquids ingress into the appliance.
• If the Display does not function.
• If the housing of the Programming and Display Unit is damaged.
• If the PROG or RESET buttons do not function.
All repairs should only be carried out by an Authorised Service Agent.
3.5 Disclaimer
Information contained in this document is believed to be accurate at the time of publication, but does not constitute a
contractual offer. The right is reserved to alter specifications without prior notice. Illustrations and tabulated data are
for guidance only. Aquis does not assume liability for any damages, including subsequent damages, that may result
from incorrect installation or usage of the products. Aquis does not assume liability for damage caused by using parts
from other manufacturers.
3.6 Declaration of Conformity
Available on request.
4. Installation
4.1 First time installation of the CLARIS filter system with the sensor unit
For initial installation of CLARIS filter system with CLARIS Flow Sensor, first install the CLARIS filter head (see
Operation Guide "CLARIS filter systems" chapter 6).
4.2 Installation of the sensor unit to an existing CLARIS filter system
If a CLARIS filter system is already in place, follow the following steps:
1. Remove connection hose from the filter head liquid outlet using an appropriate tool.
2. Connect the sensor unit with the nut directly to the filter head (use the provided flat gasket).
3. Connect the hose to the outlet of the sensor unit (use the flat gasket).
NOTE
Disconnect the CLARIS filter head from the water supply before start of installation.
Ensure correct alignment of sensor unit with direction of flow (arrow on the housing).
Use only appropriate tools for the installation (spanner 19 mm).
The sensor unit should be mounted horizontally.
Don't expose the Flow Sensor to any mechanical strain; particularly take care of any leverage effect
from kinked or bent hoses. If necessary brace the connections.
Use only suitable gaskets and connecting materials.
Before start of operation vent all air from the system.
4.3 Programming and Display Unit
4.3.1 Mounting with double-sided adhesive tape
1. Fasten an approx. 40 x 40 mm piece of double-sided adhesive tape to the back wall of the programming
and display unit.
2. Position the programming and display unit on the desired position.
4.3.2 Mounting using a screw
1. Flat head screw with max. 4 mm shaft diameter is recommended.
