Repair /cable replacement
For repair/cable replacement, send the defective safety transformer or the defective
halogen spotlight directly to the supplier/manufacturer.
Troubleshooting
Malfunction
Bulb is not
illuminated
Light performance
is decreased
Water in the
halogen spotlight
Light flickers

Technical Data

Nominal voltage - light
Power consumption
Bulbs
Halogen bulb socket
Transformer
Beam angle
Cable length
Parts subject to wear
Halogen bulb 10W
10
512-05 FLS 30 Pontec.p65
Directions for use
Possible cause Measure
Power supply Check power feed and fuse, check bulb,
interrupted and replace contacts if necessary
Dirt Cleaning
Seal defective Check seal and replace if required
Contacts have Clean the bulb pin
corroded
primary 230V/ 50 Hz, secondary 12 V max. 30VA
10
GB
12 V/50 Hz
max. 10 W
(Halogen bulb) 10 W
G 4
40°
2 m + 3 x 3 m
