Seite | 62
15 0..255 Dimmer 3
16 0..255 RED 3
17 0..255 GREEN 3
18 0..255 BLUE 3
19 0..255 AMBER 3
20 0..255 WHITE 3
21 STROBE 3 (only if STROBE is ON)
0..3 OFF
4 RANDOM FAST
5 RANDOM MEDIUM
6 RANDOM SLOW
7..255 Variable strobe
22 0..255 Dimmer 4
23 0..255 RED 4
24 GREEN 4
0..255
25 BLUE 4
0..255
26 AMBER 4
0..255
27 WHITE 4
0..255
28 STROBE 4 (only if STROBE is ON)
OFF
0..3
4 RANDOM FAST
5 RANDOM MEDIUM
6 RANDOM SLOW
7..255 Variable strobe
29 0..255 Dimmer 5
30 0..255 RED 5
31 0..255 GREEN 5
32 0..255 BLUE 5
33 0..255 AMBER 5
34 0..255 WHITE 5
35 STROBE 5 (only if STROBE is ON)
0..3 OFF
RANDOM FAST
4
RANDOM MEDIUM
5
RANDOM SLOW
6
Variable strobe
7..255
36 Dimmer 6
0..255
37 RED 6
0..255
38 0..255 GREEN 6
39 0..255 BLUE 6
40 0..255 AMBER 6
41 0..255 WHITE 6
42 STROBE 6 (only if STROBE is ON)
0..3 OFF
4 RANDOM FAST
5 RANDOM MEDIUM
6 RANDOM SLOW
7..255 Variable strobe
43 0..255 Dimmer 7
44 0..255 RED 7
45 0..255 GREEN 7
46 0..255 BLUE 7
47 0..255 AMBER 7
