Introduction
Thank you very much for purchasing a TASCAM IF-AN16/OUT
Analog outputs interface card.
Before connecting and using this card, please take time to read
this manual thoroughly to ensure you understand how to handle
it properly. By doing so, we hope that you will enjoy using it for
many years. After you have finished reading this manual, please
keep it in a safe place for future reference.
You can also download this Owner's Manual from the TEAC Global
Site (http://teac-global.com/).
Features of this card
•
Up to 16 channels of balanced audio signal output at
44.1/48/88.2/96kHz and 24-bit
•
Two 8-channel D-sub 25-pin balanced audio signal output
(channels 1-8 and 9-16)
•
Channel-independent digital attenuation from 0 to −14 dB (in
0.5dB steps)
Models compatible for installation
Before installing this card, check the TEAC Global Site (http://
teac-global.com/) for the latest information about the models in
which it can be installed.
DA-6400/DA-6400dp
•
Use firmware Ver 1.40 or later for these models.
Installation procedure overview
•
For installation procedures, see the Owner's Manual for the unit
in which you will install the card.
•
Always disconnect the AC cord from the main unit before
installing or removing this card.
•
Securely tighten the attachment screws on the right and the
left of the card before use.
Included items
This product includes the following items.
Keep the box and packing materials for transportation in the
future.
Please contact TASCAM Customer Support (see back cover) if any
of these items are missing or have been damaged during trans-
portation.
•
Main unit ........................................................................................................ × 1
•
Owner's Manual (this document) including warranty ...... × 1
