CUTTING DEPTH

1 Pull the cutting depth locking lever
upwards.
Caution! Make sure the tool is
switched off and unplugged.

MITRE CUTS

1 Open the angle clamping knob 16.
Caution! Make sure the tool is
switched off and unplugged.
SAW BLADE REPLACEMENT
1 Press the spindle lock
en the saw blade clamp
the hex key anti-clockwise.
Caution! Make sure the tool is
switched off and unplugged and
wear protective gloves.
3 Place a new saw blade upon the inner
washer (printed side pointing outward)
and close the saw blade safety guard 8.
Caution! Observe that the rotation
direction of the saw blade corre-
sponds with the tool.
LASER BATTERY REPLACEMENT
1 Open the laser battery
with a cross-head screwdriver.
Caution! Make sure the tool is
switched off and unplugged.
11 2
2
pin 18 and loos- 2
washers 6 with
4
compartment 20 2
Set the desired cutting depth and press
down the cutting depth locking lever
to secure it.
Set the desired angle and tighten the
angle clamping knob 16
Open the saw blade safety guard
pushing the saw blade guard knob
clockwise and remove the saw blade 5.
Make sure to keep the inner washer at
its place.
Press the spindle lock pin 18
tighten the saw blade clamp
with the hex key.
Caution! The mounting flange of the
big washer must point outwards.
Insert two button cells as indicated.
Afterwards close the laser battery
compartment 20 with a cross-head
screwdriver.
11
securely.
8
4
again and
washers 6
EN 103
