6.2
Technische Daten 64-2800 Serie
Max. Eingangsdruck: ..................................... 70, 240 bar
Regelbereiche: ............................................... 0 - 2 / 0 - 4 / 0 - 7 / 0 - 10 bar
Design Prüfdruck: ...............................................150% max. Eingangsdruck
Design Berstdruck:..............................................400% max. Eingangsdruck
Helium Leckrate innen: .................................... 1 x 10
Betriebstemperatur: Vespel
Durchflusskoeffizient: ...................................... Cv = 0,06 / Cv = 0,15
Medienberührte Teile
Gehäuse: ...................................................... Hastelloy
Membran: ..................................................... 316L Edelstahl, Hastelloy
Sitz: ............................................................. PCTFE, Vespel
Sonstige Teile:................................................. 316 Edelstahl, Hastelloy
6.2
Technical Data 64-2800 Series
Max. rated inlet pressure: ............................... 70, 240 bar
Outlet pressure ranges: ................................... 0 - 2 / 0 - 4 / 0 - 7 / 0 - 10 bar
Design proof pressure: ........................................150% of max. rated pressure
Design burst pressure: .........................................400% of max. rated pressure
Certified max. inboard leak rate: ..................... 1 x 10
Operating temperature: Vespel
Flow capacity: ............................................... Cv = 0.06, Cv = 0.15
Media Contact Materials
Body: ........................................................... Hastelloy
Diaphragm: ................................................... 316L stainless steel, Hastelloy
Seat: ............................................................ PCTFE, Vespel
Remaining parts: ............................................. 316 stainless steel, Hastelloy
: .......................... -40 °C bis +177 °C
®
PCTFE: ............................ -40 °C bis +60 °C
: .................... -40 °C to +177 °C
®
PCTFE: ...................... -40 °C to +60 °C
mbar l/s He
-9
, 316L Edelstahl elektropoliert
®
316L Edelstahl innen elektropoliert
oder 316L VAR Edelstahl innen elektro-
poliert
®
mbar l/s He
-9
, 316L SST with Electro-Polish
®
316L SST with internal Electro-Polish
or 316L VAR SST with internal Electro-
Polish
®
16
®
®
®
®
