QUICK START GUIDE
PAC K AG E C O N T E N T S
• 1 x ZOTAC ZBOX
• 2 x VESA mount
• 1 x AC Adapter
• 1 x Power Cord
• 1 x USB flash drive with OS recovery (optional)
• 1 x Antenna
• 1 x Quick Start Guide
C U S TO M I Z I N G YO U R ZOTAC Z B OX
1. Loosen the 4 screws securing the bottom cover.
2. Gently remove the cover.
I N S TA L L I N G M E M O RY M O D U L E S
1. Locate the SO-DIMM memory slots and insert a
SO-DIMM memory module into the slot at a 45
degree angle.
2. Gently press down on the memory module until
it locks into place by the arms of the memory
slot.
I N S TA L L I N G M . 2 S S D M O D U L E
1. Locate the M.2 SSD slot and insert an M.2 SSD
module into the slot at a 45 degree angle.
2. Gently press down on the M.2 SSD module,
and install the screw.
2
1
1
1
2
2
2
