Instruction manual
Quartz movement and hands
Cat.-No. 60.3024.01
Thank you for choosing this instrument from TFA.
1. Before you use this product
• Please make sure you read the instruction manual carefully.
• Following and respecting the instructions in your manual will prevent damage to
your instrument and loss of your statutory rights arising from defects due to incorrect
use.
• We shall not be liable for any damage occurring as a result of non-following of these
instructions.
• Please pay particular attention to the safety notices!
• Please keep this instruction manual safe for future reference.
2. Delivery contents
• Quartz movement
• Two different sets of hands
• Instruction manual
3. Field of operation and all the benefits of your new instrument at a glance
• Quiet "sweep" quartz movement
• Ideal to build your own clock
4. For your safety
• This product is exclusively intended for the field of application described above. It
should only be used as described within these instructions.
Caution!
Risk of injury:
• Not suitable for children under three years of age.
• Small pieces (for example screws) can be fatal if swallowed.
• Keep this device and the battery out of reach of children.
• Batteries contain harmful acids and may be hazardous if swallowed. If a battery is swal-
lowed, this can lead to serious internal burns and death within two hours. If you suspect
a battery could have been swallowed or otherwise caught in the body, seek medical help
immediately.
• Batteries must not be thrown into a fire, short-circuited, taken apart or recharged. Risk
of explosion!
• Low batteries should be changed as soon as possible to prevent damage caused by
leaking.
• Avoid contact with skin, eyes and mucous membranes when handling leaking batteries.
In case of contact, immediately rinse the affected areas with water and consult a doctor.
Important information on product safety!
• Do not expose the device to extreme temperatures, vibrations or shocks.
• Protect it from moisture.
• The clock hands are fragile and easily bendable.
5. Assembly
• Remove the screw nut and the washer.
• Make sure that the rubber washer does not get lost.
• Now put the movement with the thread in the self-made dial.
• Now attach everything (rubber washer, self-made dial and washer) with the screw nut.
• At first, insert the clock's hour hand and then the minute hand on the thread and set
both to 12 o'clock.
• Now attach everything with the clock's second hand and set it also to 12 o'clock
• Make sure that the clock hands are not bent during assembly as this could block the
movement.
6. Getting started
• Insert a new battery 1,5 V AA and ensure that the battery polarities are correct.
• The unit is ready for use.
Setting of the clock
• Turn the green setting wheel at the back and set the actual time.
• Do not turn the clock hands directly! The mechanism of the clock could be damaged.
7. Care and maintenance
• Clean the device with a soft damp cloth. Do not use solvents or scouring agents.
• Remove the battery if you do not use the device for a long period of time.
• Keep the device in a dry place.
04.09.2023 16:47 Uhr Seite 2
p C N m
www.tfa-dostmann.de
Les instructions en français peuvent être trouvées sur notre site Web.
Le istruzioni in italiano possono essere trovate sul nostro sito web.
De instructies in het Nederlands kunt u vinden op onze website.
Las instrucciones en español se pueden encontrar en nuestro sitio web.
8. Battery replacement
• Change the battery when the function of the battery becomes weak.
• Insert a new battery 1,5 V AA and ensure that the battery polarities are correct.
9. Troubleshooting
Problems Solution
➜ Ensure that the battery polarity is correct
Clock hands do not move
➜ Change the battery
➜ Change the battery
Incorrect indication
If your device fails to work despite these measures contact the supplier from whom you
purchased it.
10. Waste disposal
This product and its packaging have been manufactured using high-grade materials and
components which can be recycled and reused. This reduces waste and protects the envi-
ronment.
Dispose of the packaging in an environmentally friendly manner using the collection sys-
tems that have been set up.
Disposal of the electrical device
Remove non-permanently installed batteries and rechargeable batteries from the
device and dispose of them separately.
This product is labelled in accordance with the EU Waste Electrical and Electronic
Equipment Directive (WEEE).
This product must not be disposed of in ordinary household waste. As a consumer,
you are required to take end-of-life devices to a designated collection point for the
disposal of electrical and electronic equipment, in order to ensure environmentally-
compatible disposal. The return service is free of charge. Observe the current
regulations in place!
Disposal of the batteries
Never dispose of empty batteries and rechargeable batteries with ordinary house-
hold waste. They contain pollutants which, if improperly disposed of, can harm the
environment and human health. As a consumer, you are required by law to take
them to your retail store or to an appropriate collection site depending on national
or local regulations in order to protect the environment. The return service is free
of charge.
The symbols for the contained heavy metals are:
Cd=cadmium, Hg=mercury, Pb=lead.
11. Specifications
Power consumption: Battery 1 x 1.5 V AA (not included)
Housing dimension: 56 x 34 x 56 mm
Hands set 1 Second hand: 83 mm;
Minute hand: 76 mm;
Hour hand: 54 mm
Hands set 2 Second hand: 81 mm;
Minute hand: 76 mm;
Hour hand: 56 mm
Shaft length 17 mm
Weight: 51 g (instrument only)
Suitable for dials up to 6 mm thickness.
TFA Dostmann GmbH & Co.KG, Zum Ottersberg 12, 97877 Wertheim, Germany
No part of this manual may be reproduced without written consent of TFA Dostmann. The technical data are correct at the
time of going to print and may change without prior notice.
The latest technical data and information about this product can be found in our homepage by simply entering the prod-
uct number in the search box.
www.tfa-dostmann.de 09/23
