Limited One Year Warranty
(Commercial Applications)
T&S warrants to the original purchaser (other
than for purposes of resale) that such product is
free from defects in material and workmanship for
a period of one (1) year from the date of purchase.
During this one-year warranty period, if the product
is found to be defective, T&S shall, at its options,
repair and/or replace it. To obtain warranty service,
products must be returned to...
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other
transportation charges of the product to T&S and
the return of repaired or replaced product to the
purchaser are the responsibility of the purchaser.
Repair and/or replacement shall be made within a
reasonable time after receipt by T&S of the returned
product. This warranty does not cover Items which
have received secondary fi nishing or have been
altered or modifi ed after purchase, or for defects
caused by physical abuse to or misuse of the
product, or shipment of the products.
Any express warranty not provided herein, and
any remedy for Breach of Contract which might
arise, is hereby excluded and disclaimed. Any
implied warranties of merchantability or fi tness
for a particular purpose are limited to one year in
duration. Under no circumstances shall T&S be
liable for loss of use or any special consequential
costs, expenses or damages.
Some states do not allow limitations on how
long and implied warranty lasts or the exclusion or
limitation of incidental or consequential damages,
so the above limitations or exclusions may not apply
to you. Specifi c rights under this warranty and other
rights vary from state to state.
Attention California Residents:
"WARNING: This product contains chemicals
known to the State of California to cause cancer,
and birth defects or other reproductive harm."
P/N: 098-003111-45 Rev.3
Date: 12-1-17
Drawn: TEH
Checked: DMH 04-18-18
Approved: JHB 04-20-18
Installation and
Maintenance
Instructions
4" & 8" DECK
MOUNT BASE
FAUCET
B-0220, B-0222,
B-0225, B-0321,
and B-0325
Español:
ES
Instrucciones de instalación y mantenimiento
Français:
FR
Instructions pour l'installation et la maintenance
Deutsch:
DE
Installations- und Wartungsanleitungen
中文:
CN
安装与维护说明

Werbung

loading

Inhaltszusammenfassung für T&S B-0220

  • Seite 1 Some states do not allow limitations on how B-0220, B-0222, long and implied warranty lasts or the exclusion or limitation of incidental or consequential damages, B-0225, B-0321, so the above limitations or exclusions may not apply to you.
  • Seite 2 Exploded View...
  • Seite 3 Part Number Guide Base Faucet Assemblies Asm, Faucet (Swivel) B-0320-LN Faucet Body (Swivel) Asm, Coupling Flange 00AA Washer 001019-45 Asm, Quarter-Turn Eterna Cartridge (new style) w/ Spring Checks, Handle, Blue Index & Screw, LTC 002711-40NS w/ Spring Checks, Handle, Red Index & Screw, RTC 002712-40NS Asm, Quarter-Turn Cerama Cartridge (new style) w/ Check Valve, Handle, Blue Index &...
  • Seite 4 Nozzle Installation: Note: Nozzles should be installed fi rst. 1. If converting to a rigid nozzle, place no.13 into faucet body opening before installing nozzle. 11, 12, 14, 15 2. Insert no.10 into no.2 and rotate to front of sink. 3.
  • Seite 5 水嘴安装: 注意:水嘴应该最先安装 1. 如果需要转换为固定式鹅颈,只需在安装水嘴前将13号装入龙头本体的开口内。 2. 在2号中装入10号,并旋转至水槽前方。 3. 用扳手将16号拧紧。 旋转维修或替换15号(O型圈)及15号(套筒): 4. 将14号装到11号上,将15号装到11号上,并在18号上涂上大量的润滑油。将另一个14号 安装到11号上。(详见放大图) 8” Faucet Installation: [20cm] 5. Shut off water supply and drain lines. Drill (2) two holes, approximately 1” [2.5 cm] diameter in wall with 8” [20 cm] centers, where you are installing no.1. 6.
  • Seite 6 water supply line (supplied by others) Linea de surtido countertop countertop (surtidos por otros) Cubierta superior Cubierta superior Wasserleitungsrohr (nicht in der Lieferung Comptoir Comptoir tuerca enthalten) Arbeitsfl äche Arbeitsfl äche L’écrou 台面 台面 Le tuyau qui fournir l’eau Mutter 螺母...
  • Seite 7 RELATED T&S BRASS PRODUCT LINE B-0245 Deck Mount Mixing Faucet w/ 18” Double Joint Swing Nozzle T&S BRASS AND BRONZE WORKS, INC. A fi rm commitment to application-engineered plumbing products 2 Saddleback Cove, P.O. Box 1088, T & S Brass-Europe Travelers Rest, SC 29690 ‘De Veenhoeve’...
