5 Quick Check

Take readings without saving for a quick evaluation.
1 Name
4 Context Menu
1. Place instrument on first sample to be measured.
2. Perform a reading:
3. During reading a colored bar indicates the measuring progress.
4. The results of the data evaluation are displayed.
5. Change orientation Vert | Hor if required.
6. When no. of readings per sample is reached, proceed with next sample.
7. To end Quick check mode, select End test series from the context menu.
301 200 083 - 2309
1
4 3
Name of current sample.
Allows to delete, rename, interrupt
...
– Press and hold the Operate button to initialize.
– Move evenly and slowly across the sample.
wave scan 3 / wave scan 3 dual
2
2 Statistics
Readings taken compared to no. of
defined readings.
3 Orientation
Allows to switch from vertical to ho-
rizontal or vice versa.
