IMPORTANT NOTES This guide is an aid for the professional installation of the device. Please note the following notes before installation: • Always handle all parts of the device and the components of your vehicle with care. • Under all circumstances observe the regulations of the vehicle manufacturer and do not make any changes to the vehicle which could impair driving safety.
Lay the supplied cable sets and antennas in the vehicle. Please note the information on the next page. Then connect all cable sets, antennas and dongles to the ESX main device as described on page 6. Then plug in the cable plug from the radio slot of the vehicle on the ESX main unit or on its vehicle-specific system cable set.
SCOPE OF DELIVERY ITEM FIGURE QUANTITY Main device Art.-Nr. VN940-4G System cable set with ISO connector (20-pin plug) Art. No. ZEOS-A80650-022 AV cable set 1 with audio and video connections incl. rear view camera (14-pin plug) Art. No. ZERW-120014-207 USB port 1 (4-pin plug) Art.
Seite 5
SCOPE OF DELIVERY ITEM FIGURE QUANTITY Installation friendly AV cable set 2, only connections for the additional camera (8-pin connector) Art. Nr: ZERW-120008-212 Y-adapter for the external microphone and the receiver of the separately available remote control (6-pin plug) Art. No. ZERW-121506-200 External microphone (Mini jack) Art.
WIRING DIAGRAM GPS antenna WiFi antenna Fuse 10A DAB antenna 4G/LTE antenna 20-pin system socket Inputs for AV cable sets Radio antenna (F can be assigned for later accessories) System cable set 1 (20-pin connector, black) Cable brown (BRAKE): Connection for handbrake signal (ground) Cable pink (REVERSE): Connection for reverse gear signal (+ 12V) Cable white (KEY1):...
Seite 7
WIRING DIAGRAM USB port 1 (4-pin plug, purple) Use this USB port for USB storage media. For example, the cable can be routed into the glove compart- ment so that the USB socket is accessible there. 4G/LTE dongle (6-pin plug, turquoise) Please note the information on page 10.
GENERAL INSTALLATION INSTRUCTIONS GPS antenna Remove the foil on The GPS antenna should be glued horizontally to the dashboard with the the bottom of the adhesive side down. Reception is not possible with a metal-coated pane. GPS antenna Choose a level spot with a clear view of the sky. The location should be about 50 - 70 cm away from the main unit, otherwise the GPS measurement accuracy will decrease.
Seite 9
rt werden. Verstärkereinheit GENERAL INSTALLATION INSTRUCTIONS DAB antenna Naviceiver/Radio – Warten Sie, bis die Glasober äche vollständig der Frontsäule. In newer vehicles, the original vehicle antenna can usually be used for both analogue and digital radio trocken ist, bevor Sie fortfahren. reception.
Seite 10
SETUP THE 4G/LTE INTERNET CONNECTION First lay the two 4G/LTE antennas inside the dashboard towards the windshield, one an- tenna for the left and one for the right. Ideally, you should stick the antennas to the windshield to ensure optimal reception. Then insert your SIM card in the 4G/LTE dongle: Open the dongle by pushing the flap to the Now open the metal flap carefully with a...
Seite 11
SETUP THE 4G/LTE INTERNET CONNECTION Then turn on the device to test the 4G/LTE connection. After the device has started, enter your 4-digit After successful entry, the SIM card is un- PIN code of the SIM card here. Confirm the locked.
Seite 12
REAR VIEW CAMERA SETTINGS If you have connected a compatible rear view camera to the camera input of the device, the camera image is automatically displayed when you engage reverse gear. This view is also shown when the camera direct button is pressed. If your rear-view camera does not have dynamic In Settings, open the Auto Settings menu, then warning lines, you can use the device’s static...
Seite 13
REAR VIEW CAMERA SETTINGS If you have connected a compatible additional camera to the additional camera input of the device, this will be displayed via the F-CAM app. This view is also shown when pressing the camera direct button twice (refer to page 6), if the additional camera has been activated before. Under Settings, open the Car Settings menu, then If a time selection is made here instead of ON, tap on Video.
Seite 14
HD CAMERA SETTING If you use the cable set “E” for HD cameras (10-pin connector, yellow), you must change the settings in the ESX Naviceiver accordingly. To do this, proceed as follows: Apps > Settings > Car settings > Video Tap on Camera type.
Seite 15
TECHNICAL DATA / RADIO SYSTEM TYPE Function Band Information Frequency Range Max. emitted power GLONASS 1.575MHz / 1.602 MHz – AM Radio Medium wave 520 - 1.700 Hz – FM Radio Band II 87,5 - 108 MHz – DAB Radio Band III (5A –...
