CHASSIS MAINTENANCE

REMOVING THE SEAT

REINSTALLING OF THE SEAT

3
1
2

REMOVING THE AIR FILTER

1
112
4
2
Turn the Dzeus fastner
counterclockwise to release the saddle.
Remove the seat by pulling it towards the back of
the bike.
Install the saddle by sliding it forward, making sure
that the slot in the seat pan engages the post
1
in the tank. The notches
pass through the tabs on the subframe
provided for this purpose.
Lock the Dzeus fastner by turning it a quarter turn
clockwise.
The air filter is vital for the smooth operation of your
engine. Maintenance is therefore essential.
A dirty air filter reduces the performance of your bike,
increases fuel consumption and, at worst, impurities
can pass into the engine and cause premature wear.
Remove the seat.
Unscrew the thumb screw
Remove the filter with the plastic carrier
Separate the filter from its plastic holder.
a quarter turn
1
2
in the saddle must
3
that are
4
.
1
.
2
