Installation
1
Remove a plug (escutcheon)
Attach Fitting to Plate
(fittings not included)
SRGP1KO
3
SRGP4PLASTIC
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Attach Plate
Feed Wires
through Fittings
Photos and illustrations may differ slightly from actual products.
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
2
Remove a plug (escutcheon)
Attach Fitting to Plate
(fittings not included)
Note: Cable Entry Plate may appear different from the one
shown above.
4
Note: When cutting, start near the end of the nubs and test
fit the cable. If cut too far, the hole will be too big and may
require caulk or tape.
2
Attach Plate
Feed Wires
through Fittings
SRGP2KO
(Hole Count)
Cable Diameter Range:
(14) 3 mm - 7 mm
(6) 4 mm - 12 mm
(1) 16 mm - 27 mm
SRGP3RM
