Specifications - Tomahawk Mistral Handbuch

Congratulation that you took the choice to purchase this Tomahawk RC model airplane, a very good
choice from our point of view.
We at Tomahawk Aviation put a lot of attention to the overall quality of the airplane in terms of de-
sign, performance and manufacturing quality. We used all of our experience designing and building
high quality aircraft in order to present you an exceptional product. We chose high grade material
and looked after high end accessories in order to ensure top level outcome in terms of function,
performance and durability of the product. We are open and offer all necessary support in case you
should find any problem with your airplane.
As you are well aware this is a technical product. Due to its nature it is required if not mandatory to
read the instruction manual completely. Please follow the steps to complete your model as descri-
bed. It will ensure that your model will turn out in the best possible way. Please also take notice and
good care about the warning messages at the end of the instruction manual. Knowing about them
ensures that you can operate the model in the safest possible manner keeping risk away from you
and other persons. Also ensure that you comply with the latest legislation in terms of flight safety.
We at Tomahawk Aviation wish you all the best for building and especially operating your RC air-
plane. In case you have any questions please contact us. We are driven to offer the best possible
support at any time.
Span
Length
Flying weight
Wing area
Airfoil
ARF-Version
Motor Roxxy BL Outrunner C35-48-1150kV
ESC Roxxy BL Control 80A
Servos 6x Hitec HS-65MG
Servo cables Appr. 2m
Multilock 2x Mulitlock system
MPX plugs 2 pair MPX plugs
Akku 4S LiPo 2000-2500mAh
Luftschraube 11 x 8"
Spinner 38 mm
TX min. 5 Channels
RX min. 7 Channels
Glues 5min epoxy resin
UHU Por, Velcro tape
INTRODUCTION

SPECIFICATIONS

2000 mm
1180 mm
1630 g
37,95 dm²
RG-15
NEEDED ACCESSORIES
PNP-Version
Himax C3522 (1100 kV) built-in
Roxxy BL Control 80A
6x Tomahawk TDS-155 MG built-in
built-in
built-in
built-in
4S LiPo 2000-2500mAh
11 X 8" Carbon Prop included
38 mm Alu Turbo Spinner included
min. 5 Channels
min. 7 Channels
5min epoxy resin
UHU Por, Velcro tape
ENGLISH
11
