If the workpieces can be placed around the vertical coil, always use the larg-
est support yoke. The optimum efficiency is only achieved when using the
largest possible yoke. If the workpieces are heated above the horizontal yoke,
make sure that the yoke with the largest possible cross-section is always used.
In order to be able to use the units optimally, three standard yokes are avail-
able for all units. Additional support yokes in various dimensions are availa-
ble as an option. Place the yoke on the unit with the bare underside resting
evenly on both vertical yokes.
Important: The u-core and yokes contact surfaces have
been protected by anti-rust treatment. It must be remo-
ved before the first use.
