TECHNICAL DATA
= Yes
Polycarbonate body. (Isulation Class II)
Projector weight (without any accessory)
Voltage supply 110-130-220-240V AC +/- 10 % - 50/60 Hz
Voltage supply 230 V AC ( 115 V) +/- 10 % - 50/60 Hz
Fuse for: 220 - 240 V / 230 V
Power consumption (approximately)
Automatic thermal overload cut-out / Independent ventilation
Indépendent and variable ventilation
Halogen lamp 24V - 250 W (50Hours - bottom G6,35-15)
Halogen lamp 36V - 400 W (50Hours - bottom G6,35-15)
Electronic regulation ( ) or limitation ( ) of the lamp voltage
Reset tray homing
Autofocus
"TIMER" function (automatic slide change)
"AUTOSHOW" function (timer+ Homing when no slide in the gate)
A-L-C (Automatic Lampe Change)
N.S.N.L (No Slide, No Light) /
RS232 serial line..(6 pin plug)
DRA - S - K - U Mode selector
Rapid slide selection (RARO)
Lamp power controlled by built-in "TRIAC"
Screws (3) for hard fixing of the machine
————— OVERVIEW —————
1 Slide gate
2 Tray locking
3 Tray drive
4 Zero position tray sensor
5 Lamp and condenser aperture
6 Focusing knob (lens position, reference, indication)
7 Slot for lens accessories
8 Screw-feet (vertical adjustment)
9 Telescopic front feet
10 Lens holder Ø 52,5 mm Hélical and rack-mounted lens
11 Fixed carrying handle
12 Forward button
13 Reverse button
14 Bright / economy lamp switch
15 Internal / External lamp switch (In / Out)
16 Audio-visual DIN 12 pin plug or 14 pin plug
17 DIN 6 Plug
17 b SUB D9 "RS232" Plug
18 Main fuse holder
19 CEE Main plug (Class II, no earth)
20 On / Off switch
21 LED button: TIMER / AUTOSHOW mode
22 LED button: FOCUS mode
23 Ventilation grill
24 LED panel: modes and defaults
25 Manual rapid lamp change
26 Horizontal adjustment Lamp 2
27 Vertical adjustment Lamp 1 and 2
28 Horizontal adjustment Lamp 1
————— LED PANEL INFORMATION —————
30 Yellow LED projector drive command modes
31 Red
LED When slide changing
32 Green LED for "0" tray position
33 Yellow LED when using Lamp 2
34 Yellow LED : RS232 communication function
All manuals and user guides at all-guides.com
= Option
= + (A.C.D.)
"
"Auto Cooling Delay
3215
3220
3225
3235
AF
AF
7,1kg
7,1kg
7,1kg
7,1kg
–
–
–
–
T 2 A
T 2 A
T 2 A
T 2 A
350 W
350 W
350 W
350W
–
–
–
–
1
2
2
2
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
14
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
3245
3445
3240 K
3262
AF
AF
3240 K
AF
7,1kg
7,7kg
7,2kg
7,2kg
–
–
–
–
T 2 A
T 4 A
T 2 A
T 2 A
350 W
550 W
350 W
350 W
–
–
–
2
–
2
2
–
2
–
–
–
3240 AF
–
–
–
–
–
–
–
–
–
12 (1)
12 (2)
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
ENGLISH
3462
7,8kg
–
T 4 A
550 W
–
2
–
12 (2)
–
