English
Description
This adapter by Delock emulates a monitor so that the signal source
does not switch off the signal or change the resolution, even without
a connected monitor. The adapter contains a standard set of EDID/
DDC data, but it can also read and save the data of a connected
monitor.
Specification
• Connectors:
Input: 1 x HDMI-A 19 pin male
Output: 1 x HDMI-A 19 pin female
• Resolution up to 3840 x 2160 @ 60 Hz (depending on the system
and the connected hardware)
• No external power supply needed
• 1 x LED indicator
• Plastic housing
• Colour: black
• Dimensions incl. connector (LxWxH): ca. 44.0 x 20.5 x 12.5 mm
Package content
• EDID emulator
• User manual
Safety instructions
• Protect the product against moisture
• Protect the product against direct sunlight
Installation
Plug the emulator directly to the video source. Optional: Connect
the display cable to the emulator. The emulator will be in default
mode.
Please note: If you change the resolution to one supported by the
emulator, but not by the display, the display will not work.
