Troubleshooting guide
Problem
Possible cause
The machine
Flat/discharged battery.
does not start.
The battery is overheated.
Worn brushes.
Faulty power trigger.
The machine
Blunt or damaged drill bit.
is slow and/or
Too much pressure applied.
shuts off.
Flat/discharged battery.
The battery is overheated.
The motor is overheated.
Unusual sounds
The drill/screwdriver bit is
and/or strong
not centred or incorrectly
vibrations.
fitted.
Sparks in
Faulty brushes.
the motor.
Winding short circuited.
Dirty commutator.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.
Specifications
No-load speed
Battery
Torque settings
Charging time
Sound level
Vibration value
Weight
0–400/1500 rpm
18 V 2.0 Ah lithium-ion LXC series
(4.0 Ah battery available as an accessory)
15 plus a drill setting, max 45 Nm
approx. 55 mins for 2.0 Ah battery / 105 mins for 4.0 Ah battery
LpA: 70.7 dB(A) (uncertainty KpA: 3 dB)
LwA: 81.7 dB(A) (uncertainty KwA: 3 dB)
a h 0.896 m/s², K: 1.5 m/s²
a h,D 1.393 m/s², K: 1.5 m/s² (Drilling in metal)
1.6 kg with 2.0 Ah battery or 1.9 kg with 4.0 Ah battery
Solution
Recharge the battery.
Let the battery cool down.
Contact our Customer Services.
Contact our Customer Services.
Replace drill bit.
Decrease applied pressure.
Recharge the battery.
Let the battery cool down.
Let the machine cool down.
Make sure that the drill/screwdriver
bit is centred, correctly inserted
and securely fixed.
Contact our Customer Services.
