Beachte: Einige der gelisteten Teile sind bereits vormontiert!
Note: Some of this parts may come pre-installed!
Item No.:
Quantity
1
7
2
9
3
2
4
1
5
2
6
1
7
3
8
2
9
4
10
4
11
1
12
2
13
1
14
1
15
2
16
1
17
4
18
1
19
1
20
1
21
2
22
1
23
1
24
2
25
1
26
1
27
2
(*1) only MT-LMO-10-FW Plate-Load
(*2) only MT-LMO-10 SW Stack Weight
MT-PR-10-LMO-10-FW/SW Power Rack mit Latzugstation
Part-Name
Auto-Lock-Nut M10
Auto-Lock-Nut M12
Brass Flange-Bushing 12F
Button-Head-Screw M10x25
Button-Head-Screw M10x45
Button-Head-Screw M10x50
Button-Head-Screw M10x95
Button-Head-Screw M12x120
Button-Head-Screw M12x30
Button-Head-Screw M12x65
Button-Head-Screw M12x70
Button-Head-Screw M12x85
CABLE UNIT - LOWER
CABLE UNIT - UPPER
Carabiner 8mm
Chain
INJECTION-MOULDED BUSHING Ø25
LABEL "MegaTEC"
Locking-Bolt Ø10*120 yellow
(*1) LTO/LMO-WS-2
MT Rubber-Shoe 60
MT-LM-FW/WP-10(1)-10001
MT-LM-FW/WP-10(1)-20001
MT-LM-FW/WP-10(1)-30001
MT-LM-FW/WP-10(1)-40001
MT-LM-FW/WP-10(1)-50001
(*1) MT-LM-FW/WP-10(1)-60001
Item No.:
Quantity
Part-Name
28
2
MT-LM-FW/WP-10(1)-70001
29
4
Pulley Ø114/90/25
30
2
Pulley Ø88/67/25
31
1
Rectangular End-Cap 80x40mm
32
2
Reinforcementplate 100/Ø14/40
33
1
Reinforcementplate 120/Ø14/40
34
2
Reinforcementplate 50/Ø14/40
35
2
Roller-Foam
36
2
Round End-Cap Ø25mm
37
2
Round End-Cap Ø30
38
2
Rubber-Bumper_Ø25/Ø50x15
39
2
Rubber-Bumper_Ø30/Ø80x15
40
4
Snap-Ring Ø40mm
41
2
(*1) Spring Collar
42
4
Square End-Cap 40x40mm
43
7
Washer M10
44
9
Washer M12
45
1
(*2) Leading-Weight
46
1
(*2) Pick-Up-Bar 115KG
47
22
(*2) Weight-Plate 5,0KG
48
4
(*2) Plastic Sliding Bearing LW
49
44
(*2) Plastic Sliding Bearing WP
50
1
(*2) Locking Pin Ø10
51
23
(*2) Sticker 5-115KG
STÜCKLISTE
PART LIST
