Contents
1.
1 x 8 PLUS-MINUS High-voltage device with ultrasound
EN
2.
6 x PLUS-MINUS stainless steel contact plates
3.
1 x High voltage warning sti cker
4.
1 x Batt ery change reminder sti cker
5.
14 x Countersunk screws 3.5 x 9.5 DIN 7982
6.
2 x 3 V CR 2477 butt on batt eries
7.
14 x Cable ti es
1.
1x
Technical data
Operati ng voltage:
Power consumpti on:
Batt ery life:
Output voltage:
Ultrasound frequency:
Dispersion radius:
Dispersion angle:
Sound pressure:
Functi on control light:
Moisture protecti on:
Please note before installing
1.
Please prominently att ach the included yellow warning sti cker (3) in the engine compartment (e.g. on the air fi lter
housing). Att ach the batt ery change reminder sti cker (4) in a prominent place (e.g. in the vehicle's service book).
2.
The unit is largely maintenance-free. Prolonged use may lead to contaminati on of the contact plates, which can
cause the high voltage to break down (functi on control LED shuts off ).
Correcti ve
measure: Open the slide contact (the device will turn itself off ), wait approx. 3–5 minutes, then clean/
reatt ach the plates (using cable ti es) and close the slide contact again. Carefully check that the contact plates (2)
are correctly installed in order to avoid a short circuit, for example due to current leakage or the upper plus plate
coming into contact with an earthed part.
3.
Once the device is switched on, it takes several seconds before ultrasound is emitt ed. As soon as ultrasound is
being emitt ed, the green functi on control LED will begin to blink. When the device is operated for the fi rst ti me,
the green functi on control LED should begin to blink green within no more than 1 minute.
Cauti on!
Please dispose of used batt eries safely.
8
2.
3.
6x
1x
2 x 3 V (butt on batt eries)
approx. 0.2 mA (including aft er a short circuit)
up to 18 months
approx. 300 V
20–25 KHz, frequency modulati on
360°
>170°
approx. 110 dB
LED
waterproof in accordance with IP 65
4.
5.
1x
14x
6.
7.
2x
14x
