Inhaltszusammenfassung für D-Link mydlink DCS-8620LH
- Seite 1 DCS-8620LH 2K QHD Outdoor Wi-Fi Camera User Manual 03/25/2022 Hardware: A1 Manual Version: 1.01...
-
Seite 2: Manual Overview
Manual Overview D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Information in this document may become obsolete as our services and websites develop and change. -
Seite 3: Inhaltsverzeichnis
App Camera Setup ............8 Device Placement ...............10 Mounting the Camera...............11 Pole Mount ................11 Wall/ Ceiling Mount ............12 Using the mydlink App ............14 Controlling Your Device ............14 Device Settings ................15 Troubleshooting ..............17 Technical Specifications ..........18 Regulatory Information ..........20 D-Link DCS-8620LH User Manual... -
Seite 4: Product Overview
If any of the above items are missing, please contact your reseller. Note: Using a power supply with a different voltage rating than the one included with your product will cause damage and void the warranty for this product. D-Link DCS-8620LH User Manual... -
Seite 5: Introduction
• A router connected to your broadband modem • iPhone®, iPad®, Android™ smartphone or tablet (please refer to the mydlink™ App Requirements mobile app's store page to check whether your device is compatible) • Email account (for mydlink™ service registration) D-Link DCS-8620LH User Manual... -
Seite 6: Hardware Overview
Refer to LED Behavior on page 5 for more information. Microphone Picks up sound near your camera. The IR-Cut removable filter switches between color and infrared according to the Light Sensor lighting conditions monitored by the sensor. Camera Lens Records video of the surrounding area. D-Link DCS-8620LH User Manual... -
Seite 7: Bottom
Transmits sound for the two-way audio feature. microSD Card Slot microSD card slot, supports up to 256 GB. Hold the recessed button down until the Status LED turns red to reset the camera to Reset Button factory default settings. D-Link DCS-8620LH User Manual... -
Seite 8: Led Behavior
Section 1 - Product Overview LED Behavior Status LED Connected to Wi-Fi and mydlink. Powering on. Ready for configuration. Status LED Upgrading firmware - do not power off. Timeout for setup - please power cycle the device. D-Link DCS-8620LH User Manual... -
Seite 9: Installation
• Be sure to plug the device into a properly grounded electrical outlet in order to help prevent against electrical shock. • Make sure that the device is firmly mounted. D-Link DCS-8620LH User Manual... -
Seite 10: Wireless Installation Considerations
Materials and objects such as glass, steel, metal, walls with insulation, water (fish tanks), mirrors, file cabinets, brick, and concrete will degrade your wireless signal. 4. Keep your product away at least 1 to 2 meters (3 to 6 feet) from electrical devices or appliances that generate RF noise. D-Link DCS-8620LH User Manual... -
Seite 11: Mydlink App Camera Setup
Launch the mydlink app and create a new account or sign in to your existing account. Note: If you are asked about allowing the app to access your location or to send notifications, select Allow. Make sure location services and Bluetooth are turned on in your phone’s settings. D-Link DCS-8620LH User Manual... - Seite 12 Power on the device and wait for the Status LED to flash orange. Note: Make sure that your mobile device’s Bluetooth is on. Place your device next to your mobile device. A prompt will appear - tap Add Device, then follow the app instructions. DCS-8620LH D-Link DCS-8620LH User Manual...
-
Seite 13: Device Placement
Person Detection: Person Detection works best when the subject is between 2 to 7 meters (6.5 to 23 feet) away from the camera. 2 - 2.5m (6.5 - 8ft.) 2m (6.5ft.) Ideal Viewing Distance: 2 - 7 m (6.5 - 23ft.) D-Link DCS-8620LH User Manual... -
Seite 14: Mounting The Camera
Wrap the cable ties around the pole and thread them through the holes on the mounting bracket. Face the rough side of the cable ties to the pole to avoid slippage. Twist the camera clockwise onto the mounting bracket until it securely locks into place. D-Link DCS-8620LH User Manual... -
Seite 15: Wall/ Ceiling Mount
Note: The mounting bracket is attached to the bottom of the device. Turn the mounting bracket counterclockwise to detach it. Use a 6 mm drill bit to drill two 26 mm deep holes over the pencil marks. Hammer in the plastic wall anchors to support the screws. D-Link DCS-8620LH User Manual... - Seite 16 For outdoor installations: This device is designed to be installed under eaves or similarly covered locations, and does not support inverted installation. Please ensure that the device is installed with the rubber plug pointed downwards towards the ground, and that it is not installed in an area where it will experience continuous water exposure. D-Link DCS-8620LH User Manual...
-
Seite 17: Using The Mydlink App
The siren Siren will turn off automatically after the timeout period has been reached. to use 1440p resolution video. Tap Video Resolution 720P to use 720p resolution video. D-Link DCS-8620LH User Manual... -
Seite 18: Device Settings
To access the Device Settings page: 1. Tap 2. Tap Device Settings. 3. Tap the device you want to access its settings. The device page contains several options for you to configure your camera. DCS-8635LH-2AE9 DCS-8620LH D-Link DCS-8620LH User Manual... - Seite 19 Tap to enable ONVIF to allow ONVIF-compatible devices to manage the camera. MAC ID A unique physical address for identifying your device. Restart Device Tap this button to restart the device Remove Device Tap this button to disconnect this device from your mydlink account. D-Link DCS-8620LH User Manual...
-
Seite 20: Troubleshooting
What is my username and password for setting up my device with an ONVIF system? To connect your device to an ONVIF system, enter “admin” as the username and use the PIN code of your mydlink device as the password. You can find the PIN code on your device’s label. D-Link DCS-8620LH User Manual... -
Seite 21: Technical Specifications
Max. Power Consumption • 5 W Cable Length • Device: 4 m (13.12 ft) • Adapter: 3 m (9.84 ft) Indoor/Outdoor • For outdoor use (with IP65 protection) Operating Temperature • -25 to 45°C (-13 to 113°F) D-Link DCS-8620LH User Manual... - Seite 22 Subscription required. Subscription and One Year Free Plan offer subject to Terms and Conditions, please visit the D-Link website for more details. D-Link reserves the right to amend Terms and Condi- tions without prior notice.
-
Seite 23: Regulatory Information
2. This device must accept any interference received, including interference that may cause undesired operation. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. D-Link DCS-8620LH User Manual... - Seite 24 3.for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits specified for point-to-point and non-point-to-point operation as appropriate. D-Link DCS-8620LH User Manual...
- Seite 25 Max. Output Power (EIRP) Frequenzband Max. Output Power Fréquence bande(s) Consommation d’énergie max. Bandas de Frecuencia Potencia máxima de Salida Frequenza/e Potenza max. Output Frequentie(s) Max. Output Power 2.4 G 2.4 – 2.4835 GHz 100 mW D-Link DCS-8620LH User Manual...
-
Seite 26: European Community Declaration Of Conformity
υλικολογισμικό του προϊόντος είναι διαθέσιμα για λήψη από τη σελίδα του προϊόντος στην τοποθεσία www.dlink. com. Par les présentes, D-Link Corporation déclare que ce produit, ces accessoires et ce logiciel sont conformes aux Français [French] directives 2014/53/UE.Le texte complet de la déclaration de conformité de l'UE et le icroprogramme du produit sont disponibles au téléchargement sur la page des produits à... - Seite 27 2014/53/EU. Pełen tekst deklaracji zgodności UE oraz oprogramowanie sprzętowe do produktu można pobrać na stronie produktu w witrynie www.dlink.com. Desta forma, a D-Link Corporation declara que este produto, os acessórios e o software estão em conformidade Português [Portuguese] com a diretiva 2014/53/UE. O texto completo da declaração de conformidade da UE e do firmware...
- Seite 28 2014/53/EU. Hela texten med EU-försäkran om överensstämmelse och produkt-firmware kan hämtas från produktsidan på www.dlink.com. Hér með lýsir D-Link Corporation því yfir að þessi vara, fylgihlutir og hugbúnaður eru í samræmi við tilskipun Íslenska [Icelandic] 2014/53/EB. Sækja má ESB-samræmisyfirlýsinguna í heild sinni og fastbúnað vörunnar af vefsíðu vörunnar á www.
- Seite 29 Access Points unterstützen die Funktionen DFS (Dynamic Frequency Selection) und TPC (Transmit Power Control) wie erforderlich bei Betrieb auf 5 GHz innerhalb der EU. • Bitte schlagen Sie im Handbuch oder Datenblatt nach nach, ob Ihr Gerät eine 2,4 GHz und / oder 5 GHz Verbindung nutzt. D-Link DCS-8620LH User Manual...
- Seite 30 5 Ghz dentro de la UE. • Por favor compruebe el manual o la ficha de producto para comprobar si el producto utiliza las bandas inalámbricas de 2.4 GHz y/o la de 5 GHz. D-Link DCS-8620LH User Manual...
- Seite 31 Toegangspunten ondersteunen DFS (Dynamic Frequency Selection) en TPC (Transmit Power Control) functionaliteit zoals vereist bij gebruik in 5 GHz binnen de EU. • Raadpleeg de handleiding of de datasheet om te controleren of uw product gebruik maakt van 2.4 GHz en/of 5 GHz. D-Link DCS-8620LH User Manual...
-
Seite 32: Safety Instructions
• Halten Sie das Produkt von Heizkörpern und anderen Quellen fern, die Wärme erzeugen. • Trennen Sie das Produkt immer von der Stromzufuhr, bevor Sie es reinigen und verwenden Sie dazu ausschließlich ein trockenes fusselfreies Tuch. D-Link DCS-8620LH User Manual... -
Seite 33: Consignes De Sécurité
• Mantenga el producto alejado de los radiadores y de otras fuentes de calor. • Desenchufe siempre el producto de la alimentación de red antes de limpiarlo y utilice solo un paño seco sin pelusa. D-Link DCS-8620LH User Manual... -
Seite 34: Istruzioni Per La Sicurezza
• Houd het product uit de buurt van radiators en andere warmtebronnen. • U dient het product steeds los te koppelen van de stroom voordat u het reinigt en gebruik uitsluitend een droge pluisvrije doek. D-Link DCS-8620LH User Manual... -
Seite 35: D-Link Und Die Umwelt
D-Link designs and builds its products to be as environmentally friendly as possible, by using recyclable, low toxic materials in both products and packaging. D-Link recommends that you always switch off or unplug your D-Link products when they are not in use. By doing so you will help to save energy and reduce CO2 emissions. - Seite 36 D-Link et l’environnement Chez D-Link, nous sommes conscients de l'impact de nos opérations et produits sur l'environnement et nous engageons à le réduire. Pour limiter cet impact, D-Link conçoit et fabrique ses produits de manière aussi écologique que possible, en utilisant des matériaux recyclables et faiblement toxiques, tant dans ses produits que ses emballages.
- Seite 37 D-Link zijn producten zo milieuvriendelijk mogelijk, door het gebruik van recycleerbare producten met lage toxiciteit in product en verpakking. D-Link raadt aan om steeds uw D-Link producten uit te schakelen of uit de stekker te halen wanneer u ze niet gebruikt. Door dit te doen bespaart u energie en beperkt u de CO2-emissies.
- Seite 38 D-Link a životní prostředí Ve společnosti D-Link jsme si vědomi vlivu našich provozů a výrobků na životní prostředí a snažíme se o minimalizaci těchto vlivů. Proto své výrobky navrhujeme a vyrábíme tak, aby byly co nejekologičtější, a ve výrobcích i obalech používáme recyklovatelné a nízkotoxické materiály.
- Seite 39 D-Link produkter som er så miljøvennlig som mulig, ved å bruke resirkulerbare, lav-toksiske materialer både i produktene og forpakningen. D-Link anbefaler at du alltid slår av eller frakobler D-Link-produkter når de ikke er i bruk. Ved å gjøre dette hjelper du å spare energi og å redusere CO2-utslipp.
- Seite 40 D-Link sine produkter, så de er så miljøvenlige som muligt, ved at bruge genanvendelige materialer med lavt giftighedsniveau i både produkter og emballage. D-Link anbefaler, at du altid slukker eller frakobler dine D-Link-produkter, når de ikke er i brug. Ved at gøre det bidrager du til at spare energi og reducere CO2-udledningerne.
- Seite 41 D-Link och miljön På D-Link förstår vi och är fast beslutna att minska den påverkan våra verksamheter och produkter kan ha på miljön. För att minska denna påverkan utformar och bygger D-Link sina produkter för att de ska vara så miljövänliga som möjligt, genom att använda återvinningsbara material med låg gifthalt i både produkter och förpackningar.
